Hatco C-7-240-1-QS Quick Ship High Temp & Low Temp Dishwashers
Description
Hatco “Quick Ship” Compact Electric Booster Heater
6 gal | 7 kW | 240 V / 60 Hz / 1-phaseGet your dishmachine up to NSF-required 180 °F (82 °C) final-rinse temperatures in seconds. The Hatco Quick Ship C-7 Compact Booster Heater delivers powerful 7 kW performance in a space-saving footprint that’s pre-plumbed, pre-wired, and ready to install right next to your dishwasher.
Why you’ll love it
- 6-gallon (23 L) storage tank—perfect for under-counter & door-type machines
- Castone® lined tank with 10-year limited warranty resists corrosion & liming
- Delivers up to 70 gph at 40 °F rise or 40 gph at 70 °F rise
- Factory-installed temperature/pressure relief valve, pressure-reducing valve & dual gauges
- Built-in safety: high-limit cutoff, low-water cutoff & indicator pilot light
- Swing-away stainless front panel for fast service access—no tools required
- Rugged powder-coated silver-gray hammertone body & stainless steel front
- 6" (152 mm) NSF-approved plastic legs—no field adjustment needed
- Made in USA, NSF & cULus listed; ships in 10 days or less through Hatco’s Quick-Ship program
Technical specifications
| Model | Quick Ship C-7 (Compact Series) |
|---|---|
| Storage capacity | 6 gal / 23 L |
| Power | 7.0 kW, 240 V, 60 Hz, 1-phase |
| Amps / recommended breaker | 29.2 A / 40 A |
| Temperature rise | 70 gph @ 40 °F rise • 40 gph @ 70 °F rise |
| Operating temperature | 180 °F (82 °C) final rinse |
| Inlet / outlet | ¾" NPT female (pre-plumbed) |
| Dimensions (W × D × H) | 13.06" × 20.69" × 13.78" (Add 6" for legs) |
| Construction | Stainless steel front, powder-coated steel body, Castone® tank |
| Certifications | NSF, cULus, Made in USA |
| Standard warranty | 10 yr tank • 1 yr parts & labor |
Integrated controls
- Calibrated immersion thermostat
- On/Off rocker switch with green power light
- High-temperature limit (manual reset)
- Low-water cut-off to protect elements
- Dual temperature/pressure gauges for quick diagnostics
Easy installation
- Factory wired & plumbed—connect water, power, and go
- Electrical knockouts on left side & bottom (¾", 1", 1¼")
- Optional slide brackets for under-dishtable mounting (sold separately)
Need help sizing or installing? Chat with our equipment specialists—most Quick Ship orders leave the warehouse in 24 hrs.
