Hatco

Hatco Compact Electric Booster Water Heater for Dishwashers, 6 Gallon, 7 kW, 208V

SKU: C-7-208-1-QS
GTIN: 61570001039
$2,593.80
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Booster Heaters Commercial Dishwashers Dish Room Equipment Dishwashers Hatco High Temp & Low Temp Dishwashers New Arrivals Restaurant Equipment

Hatco Compact Electric Booster Water Heater for Dishwashers, 6 Gallon, 7 kW, 208V

Quick Ship Model

Space-saving booster heater delivers the 180°F final rinse water needed to sanitize and flash-dry dishes in a compact 6-gallon design.

  • Compact 6-gallon electric booster heater for commercial dishwasher final-rinse applications.
  • 7.0 kW, 208V, 60 Hz, single-phase operation.
  • Castone® lined tank with a 10-year limited warranty.
  • Factory pre-plumbed and pre-wired for easier installation and service.
  • Includes a temperature/pressure relief valve, pressure reducing valve, two gauges, and low-water cut-off protection.
  • Stainless steel front panel with a powder-coated silver-gray hammertone body.
  • Standard 6-inch plastic non-adjustable legs with slide bracket mounting available as an option.

Overall Dimensions:

13.0"W x 20.75"D x 19.75"H

Product Weight:

118.0 lb

180°F Final Rinse Performance

Provides the hot final-rinse water needed to sanitize and flash-dry dishes and flatware.

6-Gallon Storage Capacity

Compact tank size helps save space while supporting dishwasher rinse demand.

Castone® Lined Tank

Durable lined tank construction with a 10-year limited warranty.

Factory Pre-Plumbed and Pre-Wired

Arrives with internal plumbing and wiring completed for easier installation.

Integrated Safety Controls

Includes a calibrated immersion thermostat, high-temperature limit switch, and low-water cut-off to help protect the heater.

Included Plumbing Components

Supplied with a temperature/pressure relief valve, pressure reducing valve, two temperature/pressure gauges, and 3/4-inch NPT inlet and outlet fittings.

Durable Exterior Construction

Features a stainless steel front panel with a powder-coated silver-gray hammertone body.

Standard 6-Inch Legs

Mounted on 6-inch plastic non-adjustable legs; slide brackets are available for under-dishtable installation.

Water Quality Requirement

Incoming water above 3.0 grains per gallon should be treated and softened before use.

Type Booster Heater
Style Compact
Installation Type Floor Model
Capacity 6 Gallons
Color Silver-Gray
Finish Powder-Coated Hammertone
Voltage 208 Volts
Amps 33.7 Amps
Watts 7 kW
Hertz 60 Hz
Phase 1-Phase
Breaker Size 50 Amps
Water Inlet Size 3/4-Inch NPT
Country of Origin USA
Shipping Width 13 Inches
Shipping Depth 21 Inches
Shipping Height 20 Inches
Shipping Weight 118 Pounds
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Warranty & Protection

10-year limited warranty on the Castone® lined tank.

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download PDF Quick ship PDF Download PDF Parts list PDF Download PDF Catalog brochure PDF Download

Frequently Asked Questions

It supplies 180°F final rinse water for commercial dishwashers to help sanitize and flash-dry dishes and flatware.
This model is rated at 7.0 kW, 208V, 60 Hz, single-phase.
The storage capacity is 6 gallons (23 liters).
It includes a temperature/pressure relief valve, pressure reducing valve, two temperature/pressure gauges, a high-temperature limit switch, and a low-water cut-off.
Yes. It is standard with 6-inch legs and is available with slide brackets for under-dishtable mounting.
Yes. Incoming water above 3.0 grains per gallon must be treated and softened before use to help maintain efficiency and service life.
