Hatco 5-Pan Refrigerated Drop-In Cold Well Bundle
Model CWBP-5 • Curved Sneeze Guard • Optional HL5-66NW Light BarPresent your salads, desserts and cold sides at food-safe temperatures and in crisp, well-lit clarity. This convenient bundle pairs Hatco’s high-performance CWBP-5 R-290 cold well with a matching tempered-glass sneeze guard and an optional 66" LED light bar, giving you a turn-key cold service station that drops cleanly into your countertop.
Why You’ll Love It
- True 5 pan capacity – fits (5) standard 12" × 20" hotel pans or fractional equivalents.
- Top-mount, angled cold-wall design blankets food with cold air for even holding without drying.
- Eco-friendly R-290 refrigerant & high-density insulation for faster pull-down and lower energy use.
- Electronic temperature control with auto-defrost – mount on the condenser or remotely (up to 4 ft).
- Stainless-steel bezel & aluminized-steel housing built to withstand busy service lines.
- 1" brass drain simplifies end-of-day cleaning; supplied pan support bars steady full-size pans.
- Factory-installed sight glass, service valves and dryer/filter speed up service & maintenance.
- Made in the USA, NSF 7 component listed and cULus certified for peace of mind.
Bundle Components
- Hatco CWBP-5 refrigerated drop-in well (self-contained, non-rotatable condenser).
- Curved tempered-glass sneeze guard with polished edges and anodized hardware.
- HL5-66NW LED light bar (optional) – bright, energy-efficient illumination without added heat.
Technical Specifications
| Pan Capacity | (5) full-size 12" × 20" pans |
|---|---|
| External Dimensions | 71" W × 27" D × 25.5" H (1803 × 686 × 648 mm) |
| Counter Cut-out | 69.125"–70" W × 25.19"–26" D |
| Horsepower | 1/2 HP self-contained condensing unit |
| Refrigerant / Charge | R-290 • 5.1 oz (144.6 g) factory charged |
| Electrical | 120 V / 60 Hz / 1-ph • 560 W • 9.3 A |
| Plug | NEMA 5-15P (pre-wired cord) |
| Total Heat Rejection | 3,135 BTU/hr |
| Drain | 1" brass drain with hose adapter |
| Certifications | NSF 7 Component, cULus, Made in USA |
Questions about cut-out sizing, sneeze-guard options or lighting configuration? Reach out via chat and our equipment specialists will be glad to help.
Overall Dimensions:
71.0"W x 27.0"D x 25.5"HProduct Weight:
245.0 lbFrequently Asked Questions
