GTI Designs E-Line ELVS-2050 Refrigerated See-Through Display Case, Self-Contained, Full-Service, White Exterior, 82.2" Wide

SKU: ELVS-2050
$20,908.80
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Display Refrigeration Food Displays & Merchandisers General Refrigerated Display Cases GTI Designs New Arrivals Refrigerated Display Case Equipment Refrigeration & Ice Restaurant Equipment

The E-Line ELVS-2050 is a self-contained refrigerated see-through display case with a white exterior and full-service configuration.

It features a fully refrigerated lower deck, two dry/ambient upper shelves, LED lighting under each shelf, electronic digital temperature control, a stainless steel interior, and a stainless steel rear serving shelf. Dry storage is provided under the counter.

  • Standard straight glass with front glass access for cleaning
  • Plexiglass rear sliding doors
  • Ventilated cooling system with condensation pan
  • Adjustable equipment legs and heavy-duty casters

Overall Dimensions:

82.2"W x 35.5"D

Self-contained refrigeration

Ventilated cooling system with a refrigerated lower deck and condensation pan; no floor drain is required.

Dry and refrigerated display levels

The bottom level is fully refrigerated, while the top two shelves are dry/ambient.

LED lighting

LED lighting is provided under each shelf; the technical data lists 3000 K lighting.

Electronic temperature control

Electronic digital control panel for temperature control.

Stainless steel construction

Stainless steel interior and stainless steel rear serving shelf.

Glass access

Standard straight glass with front glass access for cleaning and plexiglass rear sliding doors.

Under-counter storage

Dry storage is provided under the counter.

Mobility and leveling

Includes adjustable equipment legs and heavy-duty casters.

Exterior Finish White exterior, RAL 9003 standard
Refrigeration Self-contained refrigeration
Cooling System Ventilated cooling system
Service Type Full service
Display Type See-through
Display Glass Straight glass (VD), standard
Shelf and Deck Arrangement Refrigerated lower deck with two dry/ambient upper shelves
Lighting LED, 3000 K
Temperature Control Electronic digital control panel
Interior and Rear Serving Shelf Stainless steel
Under-counter Storage Dry storage
Display Capacity 4.45 cu. ft.
Amperage 10 A
Motor Power 1/2 HP
Plug NEMA 6-15P
Electrical Requirement 220 V / 60 Hz / 1 Ph
Refrigerant R404A / R452A
Listed Temperature 41°F / 45°F
Condensation Management Condensation pan; no floor drain required

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed
Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

Yes. The ELVS-2050 has self-contained refrigeration and a condensation pan, so no floor drain is required.
The lower deck is fully refrigerated. The top two shelves are dry/ambient.
The listed requirements are 220 V, 60 Hz, single phase, with 10 A service and a NEMA 6-15P plug.
Yes. The product includes dry storage under the counter.
It uses standard straight glass, identified as VD, with front glass access and plexiglass rear sliding doors.
