Groen  |  SKU: TDH-24C

Groen TDH-24C Steam Kettles

$15,635.00
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Groen TDH-24C Gas Table-Top Tilting Kettle – 24 Qt

Self-contained 2/3-jacket kettle with Classic IPX6 electronic controls

Bring boiler-free steam power to your worktable. The Groen TDH-24C delivers 24 quarts (6 gal) of even, jacketed heat for soups, sauces, stocks and more—all from a compact, hand-tilt kettle that runs on an efficient 31,000 BTU gas burner.

At-a-Glance Benefits

  • 24 qt / 22.7 L capacity—batch-cook up to 200 portions in one go.
  • 2/3 steam jacket surrounds product for gentle, uniform heating with virtually no scorching.
  • Fin-tube burner generates its own steam; no external boiler or water connections needed.
  • IPX6 Classic control panel with power switch, 1-10 temp dial, HEAT & LOW-WATER indicators.
  • Manual hand-tilt with reversible handle for smooth, single-operator pouring.
  • 304 stainless-steel liner & full stainless exterior—durable, sanitary and easy to keep spotless.
  • Built-in safety: tilt shut-off, hi-limit pressure switch, pressure-relief valve & low-water cut-off.
  • Factory-sealed jacket pre-charged with treated water—zero boiler maintenance.

Technical Specifications

Model TDH-24C (Classic Controls)
Capacity 24 qt / 6 gal / 22.7 L
Jacket 2/3 steam jacket, factory sealed & pressurized
Heat Input 31,000 BTU/hr
Temperature Range 150 °F – 295 °F (65 °C – 146 °C)
Working Pressure 50 PSI (ASME stamped)
Tilt Mechanism Hand-tilt, right-side console (shuts heat off when tilted > 12°)
Gas Connection ½″ NPT, Natural or Propane, 0 – 2,000 ft elevation
Electrical 115 V / 60 Hz, single phase (controls & ignition)
Water & Dust Rating IPX6 splash-proof control enclosure
Liner Material 304 stainless steel, 180-grit interior polish
Exterior Finish High-buff stainless steel
Dimensions (W×D×H) Refer to spec sheet
Net Weight Approx. 141 lb (64 kg)

Certifications & Compliance

  • cCSAus gas & electrical certification
  • ASME code stamped & NB registered (50 PSI)
  • NSF listed for sanitation
  • IPX6 water-resistant controls
  • Made in the USA

Optional Accessories

  • TS/10-3 stainless table-top support stand (with or without drain drawer)
  • Lift-off or hinged cover
  • Wire or nylon basket inserts
  • Single or double pantry faucets
  • Cover holder & cover strainer

Warranty

Includes Groen’s 1-year parts & labor warranty; extended coverage available at purchase. Nationwide service network for prompt support.

Features & Specs

Manufacturer

Groen

Certifications

NSF, cCSAus, IPX6, Made in USA

Height

26.63in

Width

25.63in

Depth

25.5in

Shipping Weight

220.0lbs

Capacity

6 gal = 24 qt

Kettle Jacket

partial jacket

Support location

right

Tilt type

arm

Kettle Liner

stainless steel

Specifications

Kettle, gas, table top, 24 quart capacity, 2/3 jacket, IPX6 water rated electronic Classic controls, 304 stainless steel liner, hand tilt, support console on right, stainless steel construction, 50 PSI, 0 - 2000' elevation, 31,000 BTU, cCSAus, NSF, Made in USA
