Groen TDH-20A Steam Kettles
Description
Groen TDH-20A 20-Quart Gas Table-Top Tilting Kettle – Advanced Controls
IPX6 water-resistant • 2/3 steam jacket • Made in USAEngineered for demanding commercial kitchens, the Groen TDH-20A delivers 20 quarts of consistent, steam-jacketed cooking power in a compact table-top footprint. 304 stainless steel construction, intuitive electronic controls and a patented 31,000 BTU burner make this kettle the smart choice for high-quality soups, sauces, custards and more.
Why chefs choose the TDH-20A
- 20 qt (18.9 L) capacity—handles up to 50 lb of product* with no external boiler.
- Advanced IPX6-rated electronic controls featuring:
- Bright digital display & countdown timer (1 minute – 10 hours).
- Low (level 2) & High (level 7) preset heat intensities plus full manual mode.
- 2/3 steam jacket reaches 150 – 295 °F for even, edge-to-edge heat.
- Patented fin-tube burner supplies 31,000 BTU/h with electronic spark ignition.
- Hand-tilt design with right-side console and reversible handle for precise pouring.
- ASME-stamped 50 PSI vessel; cCSAus & NSF certified for safety and sanitation.
- Proudly built in the USA and backed by Groen’s 1-year parts & labor warranty.
Built-in safety systems
- Tilt cut-off—shuts burners when kettle tilts more than 12°.
- Pressure-relief valve & high-limit pressure switch.
- Low-water cut-off protects the jacket from dry-firing.
- 24 V control circuit keeps high voltage away from operators.
Technical specifications
| Model | TDH-20A |
|---|---|
| Capacity | 20 qt / 18.9 L |
| Jacket Coverage | 2/3 |
| Heat Source | Natural or propane gas |
| Input | 31,000 BTU/h |
| Operating Pressure | 50 PSI max |
| Temperature Range | 150 – 295 °F (65 – 146 °C) |
| Elevation Rating | 0 – 2,000 ft |
| Gas Connection | ½″ NPT |
| Electrical | 115 V, 1 ph, 60 Hz, ≈1 A |
| Controls | IPX6 Advanced electronic, digital timer & presets |
| Construction | 304 SS liner, polished 180-grit interior, high-buff exterior |
| Tilt Mechanism | Manual hand-tilt, reversible handle |
| Certifications | ASME, cCSAus, NSF |
| Origin | Made in USA |
*Approximate yield based on mashed potatoes at 40 % jacket fill; actual yield varies by product.
Popular accessories (sold separately)
- TS/10-3 stainless steel table stand (with or without drain drawer).
- Lift-off or hinged kettle cover and cover holder.
- Wire or nylon basket inserts for bulk pasta or blanching.
- Single- or double-pantry faucets & pre-rinse sprayers.
From silky béchamel to small-batch stocks, the Groen TDH-20A is the compact powerhouse that keeps your production moving and your quality soaring.
