Gemini Bakery Handy V V17 Floor-Model Cookie Dough Depositor, Stainless Steel, Adjustable Pan Guide, Variable Speed Control

SKU: V17
$78,064.62
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Gemini Bakery Handy V V17 is a floor-model cookie dough depositor specified for wire-cut uniform cookies at a rate of 1,250 to 1,750 dozen per hour, depending on die choice.

  • Pan guidance: The adjustable pan guide accommodates 16- to 19-inch-wide pans.
  • Variable speed: The machine operates at 30 to 70 strokes per minute and includes separate pan speed control.
  • Cleaning: The stainless steel dough hopper and feed rolls are removable for cleaning.
  • Tables: Stainless steel hinged fold-down tables are provided on each end with aluminum pan rollers.
  • Controls and feed: A push-button starter with Dart controls and overload protection supports continuous feed through a Tubelt conveyor, with an adjustment knob for cookie thickness.
  • Power: The V17 uses a 1/3 HP motor rated at 115 V, single phase, 60 Hz.

Overall Dimensions:

31.38"W x 75.0"D

Product Weight:

660.0 lb

Adjustable pan guide

Accommodates 16- to 19-inch-wide pans.

Variable speed control

Provides 30 to 70 strokes per minute with separate pan speed control.

Stainless steel hopper

Type 302 stainless steel hopper is removable for cleaning.

Continuous dough feed

Uses a Tubelt conveyor with an adjustment knob for cookie thickness.

Fold-down tables

Stainless steel hinged tables on each end include aluminum pan rollers.

Push-button starter

Includes Dart controls with overload protection.

Drive system

Uses a silent V-belt drive with anti-friction bearings.

Electrical specification

1/3 HP motor rated at 115 V, single phase, 60 Hz, with cord and plug.

Related Searches

Best Sellers Bone & Fine China Donut Depositor Plungers & Components Equipment Food Preparation Equipment Gemini Bakery New Arrivals Restaurant Dinnerware Shop Dinnerware by Grade Tabletop
Product type Floor-model cookie dough depositor
Production rate 1,250-1,750 dozen cookies per hour
Pan guide Adjustable for 16-19 inch-wide pans
Speed range 30-70 strokes per minute
Hopper Type 302 stainless steel; removable for cleaning
Tables Stainless steel hinged fold-down tables with aluminum pan rollers
Feed system Continuous Tubelt conveyor
Motor 1/3 HP
Electrical 115 V, single phase, 60 Hz; cord and plug
Starter Push-button starter with Dart controls and overload protection
Drive Silent V-belt with anti-friction bearings
Width 31.38 in
Weight 660 lb

Warranty & Protection

New equipment is warranted against material defects for 12 months from the shipment date when installation and startup supervision are contracted by the buyer and performed by the seller's authorized representative.

Documents

PDF Cutsheet PDF Download PDF Terms & conditions PDF Download

Frequently Asked Questions

Its adjustable pan guide accommodates 16- to 19-inch-wide pans.
The listed production rate is 1,250 to 1,750 dozen cookies per hour, depending on die choice.
Variable speed control operates from 30 to 70 strokes per minute, with separate pan speed control.
Yes. The stainless steel dough hopper is removable for cleaning, and the feed rolls are also described as easily removable.
The V17 uses a 1/3 HP motor rated at 115 V, single phase, 60 Hz, with cord and plug.
