Garland UTOG36-6 US Range UT Counter Hot Plates
Description
US Range UT Counter 36" Heavy-Duty Gas Hotplate
Model UTOG36-6 • 180,000 BTU • 6 Performer Pro BurnersEngineered for relentless, high-volume production, the Garland US Range UT Counter hotplate delivers uncompromising power, durability and flexibility—perfect for boosting line capacity without sacrificing valuable floor space.
Key Features
- Six 30,000 BTU Performer Pro octagonal open burners (total 180,000 BTU/h).
- Individual manual gas valves for precise flame control on every burner.
- Split, ergonomic cast-iron grates—lightweight, dishwasher-safe and designed to shield pilots from spill-overs.
- All-stainless front, sides and back stand up to daily commercial abuse and wipe clean easily.
- 3 ½" deep stainless front rail doubles as a work surface and knob guard.
- Full-width, slide-out stainless crumb tray speeds up end-of-shift cleanup.
- 4" high stainless adjustable legs for quick, level countertop installation.
- 3/4" NPT regulator with “T” rear manifold—plumb straight through or flush-mount.
- Standing pilots for instant ignition; recessed location resists boil-over outages.
At-a-Glance Specifications
| Model | UTOG36-6 |
|---|---|
| Exterior width | 35-7/16" (900 mm) |
| Depth | 32" (814 mm) |
| Height (with legs) | 13" (330 mm) |
| Burners | 6 open-top Performer Pro |
| Total input | 180,000 BTU/h Natural • 156,000 BTU/h Propane |
| Gas connection | 3/4" NPT rear manifold (regulator included) |
| Manifold pressure | 4.5" WC Natural • 10" WC Propane |
| Operating pressure | 7" WC Natural • 11" WC Propane |
| Clearances to combustibles | 14" (356 mm) sides • 6" (152 mm) rear |
| Construction | Stainless steel body, cast-iron grates |
| Certifications | CSA • NSF |
Optional Accessories
- Stainless drop-skirt for flush counter mounting (reduces height by 1 ¾").
- Stainless equipment stand with solid top and adjustable feet or locking casters.
- Removable stainless condiment rail (1/9 or 1/3 pan cut-outs, pans not included).
Looking to create a seamless countertop lineup? Matching Garland UT griddles, charbroilers and ranges are available—chat with our equipment specialists for a custom quote.
