Garland  |  Polar Cuisine  |  SKU: UN17FC48

Garland UN17FC48 Polar Cuisine Undercounter & Worktop Refrigeration

$16,437.85
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Cutsheet Cutsheet
Related Searches
Commercial Work Tables Equipment Stands Kitchen Equipment Tables Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Garland Polar Cuisine 48" Self-Contained Freezer Base

Model UN17FC48 | One section | (2) 19" drawers

Transform the space beneath your Garland Cuisine Series modular cooktop into high-performance frozen storage. The Polar Cuisine 48" freezer base keeps ingredients ice-cold and within arm’s reach, streamlining your line while standing up to the toughest commercial kitchens.

Key features
  • Self-contained R-290 refrigeration—no remote condenser required
  • Two heavy-duty 19" drawers on stainless slide assemblies (10-year parts warranty)
  • Each drawer holds one full-size 12" × 20" × 4" hotel pan
  • Electronic temperature control with bright digital read-out and automatic defrost timer
  • Factory-tropicalized 1/3 HP compressor rated for up to 100 °F (38 °C) ambient
  • Durable stainless steel exterior front & sides; stainless interior top, rear & bottom
  • Snap-in magnetic door gaskets for effortless field replacement
  • 6" adjustable stainless steel legs provide a working height of approx. 30-3/4"
  • 8' cord with NEMA 5-15P plug (115 V single-phase, 8.2 A)
  • Warranty: 5 yrs compressor parts / 1 yr parts & labour
Specifications
Exterior width 48 in | 1219 mm
Exterior depth 32-3/4 in | 832 mm
Exterior height (with legs) 30-3/4 in | 781 mm
Sections / drawers 1 section | 2 drawers (19")
Pan capacity 2 × 12" × 20" × 4" hotel pans
Refrigerant Environmentally friendly R-290
Compressor 1/3 HP, right-side mounted
Electrical requirements 115 V / 60 Hz / 1-ph • 8.2 A • NEMA 5-15P
Shipping weight ≈ 340 lb | 154 kg
Certifications cULus, NSF
Options & accessories (sold separately)
  • 6" locking swivel casters (set of four)
  • Extra-deep drawers (6" pan depth, no mullion)
  • Door & rack kit for 18" × 26" sheet pans (not available on 32" drawers)
  • Left-side compressor configuration
  • °C temperature read-out
Important: Polar Cuisine bases are engineered exclusively for use beneath Garland Cuisine Series modular cooktops. Always specify the compatible top(s) when ordering.

Garland equipment is intended for commercial applications only and is not approved for residential use.

Features & Specs

Manufacturer

Garland

Brand_name

Polar Cuisine

Height

26.19in

Width

48.0in

Depth

32.75in

Shipping Weight

340.0lbs

Exterior Finish

all stainless steel exterior

Drawer Qty

2 drawers

Width

42" - 48" wide

Refrigeration

self-contained, side mounted

Specifications

Polar Cuisine Freezer Base, self-contained refrigeration, 48" W, one-section, (2) 19" drawers, stainless steel exterior, 6" stainless steel legs (available only when ordered with Cuisine Series modular cook tops) 115v/60/1-ph, 8.2 amps, (U S Range)
