Garland UN17C60 Polar Cuisine Undercounter & Worktop Refrigeration
Description
Garland Polar Cuisine 60" Self-Contained Refrigerated Base (UN17C60)
Two-Section | (2) 19" & (2) 27" Drawers | 115 V, 8.2 AKeep your mise-en-place perfectly chilled and only an arm’s length from the cookline. Designed exclusively for Garland Cuisine Series modular cooktops, the 60" Polar Cuisine refrigerated base delivers high-performance, low-profile cold storage without giving up valuable kitchen footprint.
Key Advantages
- Self-contained refrigeration system eliminates remote piping and speeds up installation.
- Four heavy-duty drawers (two 19" & two 27") glide on stainless roller assemblies (10-year parts warranty).
- Holds up to six full-size 12" × 20" × 4" hotel pans—perfect for high-volume prep lines.
- Eco-friendly R-290 refrigerant and CFC-free foamed-in-place insulation.
- Digital thermostat with easy-read LED display for precise temperature control.
- Compressor tropicalized to 100 °F (38 °C) for reliable performance in the hottest kitchens.
- 6" stainless-steel adjustable legs standard; optional 6" casters available.
Engineered to Sit Under Your Garland Cuisine Cooktop
With its low-height 26 3⁄16" profile, this base aligns perfectly under Garland Cuisine Series modular tops, giving chefs instant access to chilled ingredients directly beneath the cooking surface and speeding up service.
Drawer Configuration & Capacity
- (1) stack of 19" drawers, 2-high
- (1) stack of 27" drawers, 2-high
- Total pan capacity: 6 × 12" × 20" × 4" hotel pans
- Snap-in magnetic gaskets for a tight seal and fast cleaning
Technical Specifications
| Model | UN17C60 |
|---|---|
| Exterior dimensions (W × D × H) | 60" × 32 3⁄4" × 26 3⁄16" (1524 × 832 × 665 mm) |
| Sections / Drawers | 2 sections / 4 drawers (2 × 19", 2 × 27") |
| Refrigerant | R-290 hydrocarbon |
| Compressor | 1/5 HP, right-side mounted, tropicalized to 100 °F |
| Electrical | 115 V / 60 Hz / 1-ph / 8.2 A • NEMA 5-15P, 8′ cord |
| Pan capacity | 6 full-size 12" × 20" × 4" pans |
| Legs | 6" stainless-steel, height-adjustable |
| Certifications | UL, NSF |
| Warranty | 1-year parts & labor • 5-year compressor (parts) • 10-year drawer roller (parts) |
| Shipping weight | ≈ 383 lb (174 kg) |
Popular Options & Accessories
- 6" swivel casters (with restraining device)
- Extra-deep drawers for 6" hotel pans
- Left-side compressor
- Celsius temperature readout
- Door & tray-rack kit for sheet pans (not available on 32" drawers)
Garland reserves the right to modify design or specifications without notice. All data is based on manufacturer’s published information.
