Garland US Range U-Series 60-Inch Commercial Gas Range with 48-Inch Smooth Steel Griddle, 2 Open Burners, Convection Oven, and Storage Base

SKU: U60-2G48CS
$12,377.70
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Gas Ranges Commercial Ranges Garland Gas Ranges New Arrivals Ranges Restaurant Equipment

Garland US Range U-Series 60-Inch Commercial Gas Range with 48-Inch Smooth Steel Griddle, 2 Open Burners, Convection Oven, and Storage Base

Manual Controls, Stainless Steel, Floor Model

Built for busy kitchens, this 60-inch range combines burners, a full griddle, convection oven, and storage in one rugged stainless steel platform.

  • Combines 2 open burners, a 48-inch griddle, and a convection oven in one 60-inch footprint.
  • 174,000 BTU total input supports high-volume cooking and fast recovery.
  • Manual griddle control and a snap-action oven thermostat help deliver consistent results.
  • Stainless steel front, sides, plate rail, back guard, and shelf are built for daily commercial use.
  • Includes a built-in storage base plus 6-inch stainless steel legs with adjustable feet.
  • Convection oven comes with 3-position rack guides and 3 racks for flexible baking.

Overall Dimensions:

59.1"W x 34.5"D x 57.0"H

Product Weight:

815.0 lb

Two Open Burners

Two 32,000 BTU cast-iron open burners provide high-output heat for sauteing, boiling, and other top-side cooking.

48-Inch Smooth Steel Griddle

48-inch by 23-inch by 5/8-inch thick smooth steel griddle plate with manual hi/lo valve control.

Convection Oven With Rack Set

Includes 1 convection oven with 3-position rack guides, 3 racks, and a snap-action modulating thermostat.

Built-In Storage Base

Integrated storage cabinet base adds convenient under-range storage.

Stainless Steel Construction

Stainless steel front, sides, plate rail, 2-piece back guard, and shelf help the range stand up to heavy use.

120V Convection Oven Motor

Standard convection oven motor is 1/3 HP, 120V, 60 Hz, single-phase and comes with a 6-foot cord and plug.

Adjustable Stainless Steel Legs

6-inch stainless steel legs with adjustable feet help level the range on the floor.

Gas Regulator Included

Includes a gas regulator for installation.

Type Gas Restaurant Range
Style Range With Griddle And Convection Oven
Installation Type Floor Model
Material Stainless Steel
Finish Stainless Steel
Controls Manual
BTU 174,000 BTU
Cooking Surface Width 48 Inches
Cooking Surface Depth 23 Inches
Cooking Surface Thickness 5/8 Inch
Temperature Range Low to 500 Degrees F
Oven Interior Width 26-1/4 Inches
Oven Interior Depth 22 Inches
Oven Interior Height 13 Inches
Voltage 120 Volts
Amps 3.4 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Cord Length 6 Feet
Selling Unit Each
Units Per Case 1
Shipping Width 60 Inches
Shipping Depth 35 Inches
Shipping Height 57 Inches
Shipping Weight 815 Pounds

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

It includes 2 open burners, a 48-inch griddle, 1 convection oven, and 1 storage base.
The range is rated at 174,000 BTU total input.
The convection oven includes 3-position rack guides, 3 racks, and a 1/3 HP 120V, 60 Hz, single-phase fan motor.
The griddle measures 48 inches by 23 inches and uses a 5/8-inch thick smooth steel plate with manual hi/lo valve control.
No. The document states that it is not approved for residential use.
The standard motor uses a 6-foot cord with a NEMA 5-15P plug; the optional 240V motor is direct-connect only.
