US Range U-Series 60-Inch Gas Restaurant Range with 10 Open Burners, Convection Oven, and Storage Base

SKU: U60-10CS
$8,837.55
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Gas Ranges Commercial Ranges Cooking Equipment Equipment Garland Gas Ranges New Arrivals Ranges Restaurant Equipment

US Range U-Series 60-Inch Gas Restaurant Range with 10 Open Burners, Convection Oven, and Storage Base

Stainless Steel Front and Sides, Backriser with Hi-Shelf

Built for high-volume cooking, this 60-inch gas range combines 10 open burners, a convection oven, and under-range storage in a durable stainless-steel body.

  • Ten 32,000 BTU open burners provide fast, high-output cooking power across the range top.
  • One convection oven adds rack flexibility for baking, roasting, and holding.
  • Integrated storage base cabinet offers convenient dry storage below the cooking surface.
  • Stainless steel front, sides, plate rail, back guard, and shelf help with durability and cleanup.
  • 6-inch stainless steel legs with adjustable feet make installation and leveling easier.
  • Total input is rated at 358,000 BTU/hr for demanding commercial kitchens.

Overall Dimensions:

59.1"W x 34.5"D x 57.0"H

Product Weight:

690.0 lb

10 Open Burners

Ten cast-iron open burners deliver 32,000 BTU each for powerful surface cooking.

Cast-Iron Top Grates

Split cast-iron ring grates support heavy cookware and stand up to commercial use.

Convection Oven

One convection oven includes 3-position rack guides, 3 racks, and a 1/3 HP fan motor.

Storage Base Cabinet

A built-in storage base provides dry storage below the range.

Stainless Steel Construction

Stainless steel front, sides, plate rail, back guard, and shelf add durability and simplify cleanup.

Adjustable Legs

6-inch stainless steel legs with adjustable feet help with leveling on the install site.

Modulating Oven Control

Snap-action thermostat control supports even baking performance up to 500°F.

High Total Output

The range is rated at 358,000 BTU/hr total gas input.

Type Gas Restaurant Range with Convection Oven
Style U-Series
Installation Type Floor Model
Material Stainless Steel
Finish Stainless Steel
BTU 358,000 BTU
Controls Snap-Action Modulating
Temperature Range Low to 500°F
Voltage 120 Volts
Amps 3.4 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Cord Length 6 Feet
Shipping Width 60 Inches
Shipping Depth 35 Inches
Shipping Height 57 Inches
Shipping Weight 690 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

It includes 10 open burners, one convection oven, one storage base, stainless steel front and sides, a plate rail, a 2-piece back guard and shelf, and 6-inch adjustable feet.
This model has 10 cast-iron open burners rated at 32,000 BTU each.
The convection oven includes 3-position rack guides, 3 racks, a snap-action modulating thermostat, and a 1/3 HP fan motor.
The standard convection oven motor is 120V, 60 Hz, 1-phase, 3.4 amps, and ships with a 6-foot cord and NEMA 5-15P plug.
The provided product dimensions are 59.1 inches wide, 34.5 inches deep, and 57 inches high, with a weight of 690 lb.
The cutsheet also references 240V 50/60 Hz single-phase convection oven motor options and both natural gas and propane ratings.
