Garland

US Range U-Series 48-Inch Gas Restaurant Range with 4 Open Burners, 24-Inch Griddle, Convection Oven and Storage Base

SKU: U48-4G24CS
$10,110.60
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Gas Ranges Commercial Ranges Cooking Equipment Equipment Garland Gas Ranges New Arrivals Ranges Restaurant Equipment

US Range U-Series 48-Inch Gas Restaurant Range with 4 Open Burners, 24-Inch Griddle, Convection Oven and Storage Base

Stainless Steel Front and Sides, 202,000 BTU Total

This heavy-duty 48-inch gas range combines high-output burners, a flat griddle, and a convection oven to maximize cooking versatility in one commercial footprint.

  • Combines four open burners, a 24-inch griddle, a convection oven, and a storage base in one range.
  • 32,000 BTU open burners and a 5/8-inch steel griddle plate deliver strong, flexible cooking performance.
  • Convection oven includes 3 position rack guides, 3 racks, and a 1/3 HP fan motor for even baking.
  • Stainless steel front, sides, plate rail, and backguard are built for demanding kitchen use.
  • 6-inch stainless steel legs with adjustable feet help simplify leveling and installation.

Overall Dimensions:

48.0"W x 34.5"D x 57.0"H

Product Weight:

604.0 lb

Four 32,000 BTU Open Burners

Cast-iron open burners with split grates provide high heat output for boiling, sautéing, and stock-pot cooking.

24-Inch Steel Griddle

A 5/8-inch thick steel griddle plate adds a flat cooking surface for breakfast items, burgers, and sandwiches.

Convection Oven Section

Includes one convection oven with 3 position rack guides, 3 racks, and a 1/3 HP 120V fan motor for even heat circulation.

Stainless Steel Exterior Construction

Stainless steel front, sides, plate rail, backguard, and shelf help improve durability and cleanup.

Storage Base

Integrated storage base adds convenient under-range storage space.

Heavy-Duty Oven Design

Porcelain oven bottom and door liner pair with a keep-cool door handle for long-lasting use.

Service-Friendly Components

Includes a gas regulator, easy-access oven pilot, reinforced chassis, and large heavy-duty knobs.

Type Gas Restaurant Range
Style Open Burner / Griddle With Convection Oven
Installation Type Floor Model
Material Stainless Steel
Finish Stainless Steel
BTU 202,000 BTU
Voltage 120 Volts
Amps 3.4 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Cord Length 6 Feet
Gas Connection Size 3/4 Inch
Cooking Surface Width 47-1/4 Inches
Cooking Surface Depth 27 Inches
Shipping Width 48 Inches
Shipping Depth 35 Inches
Shipping Height 57 Inches
Shipping Weight 604 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

It includes four open burners, a 24-inch griddle, one convection oven, and a storage base.
Each open burner is rated at 32,000 BTU.
The standard convection oven motor is 120V, 60 Hz, 1-phase, 3.4 amps and is supplied with a 6-foot cord and NEMA 5-15P plug.
The U48-4G24CS is rated at 202,000 BTU total.
The cutsheet lists options such as a 240V convection oven motor, low-profile backguard, additional oven racks, casters, flanged deck mount legs, Celsius temperature dials, and piezo spark ignition for griddle pilots.
