Garland MST42-6T-E Master Gas Ranges
Description
Garland Master Series 34" Modular Combination Top – 2 Open Burners & 17" Even-Heat Hot Top
Model MST42-6T-E | Natural or Propane GasBuilt for the busiest commercial kitchens, the Garland Master Series modular combination top delivers 100,000 BTU of precise, even heat in a compact 34-inch footprint. Two high-performance Starfire® open burners sit beside a 17 inch Even-Heat hot top, giving chefs the versatility to sauté, simmer, sear or hold large stockpots—all on a single heavy-duty platform.
Why you’ll love it
- (2) removable two-piece Starfire open burners rated at 35,000 BTU each for rapid boil recovery.
- 17" Even-Heat hot top (27,000 BTU) with thick cast-iron plate for uniform surface holding and finishing.
- Electric spark ignition and Sentry total flame-failure protection on every burner for worry-free operation.
- Stainless steel front, sides and 7-1/2" deep front rail stand up to daily abuse and wipe clean fast.
- Heavy-gauge aluminized radiation baffle & cast-iron top grates preserve heat and improve fuel efficiency.
- Full-length stainless drip tray keeps your line clean and safe.
- 1-1/4" NPT front gas manifold for quick hook-up; rear connection kit available.
- Modular design drops onto a refrigerated base, chef’s stand or countertop—no oven means zero wasted space.
- Certified CE, CSA Star, CSA Flame & NSF for worldwide code compliance.
Technical specifications
| Overall width | 34 in / 864 mm |
|---|---|
| Overall depth | 38 in / 965 mm |
| Height (modular top) | 9-1/2 in / 241 mm† |
| Open burners | 2 × 35,000 BTU Starfire burners (removable heads & ring grates) |
| Hot top section | 1 × 17" Even-Heat plate, 27,000 BTU “H”-type burner |
| Total input | 100,000 BTU/hr (29.3 kW) |
| Gas inlet / pressure | 1-1/4" NPT front manifold Natural 6" WC / Propane 10" WC |
| Ignition | 120 V electric spark (0.1 A, 6 ft NEMA 5-15P cord) |
| Shipping weight | 255 lb / 116 kg |
| Certifications | NSF • CE • CSA Star • CSA Flame |
†Height shown with Garland low-profile modular stand. Legs, casters and other bases sold separately.
Popular options & accessories
- 10", 17" or 33" stainless backguard or high shelf.
- 6" stainless adjustable legs, dais base or polyurethane swivel casters with front brakes.
- Rear gas connection kit, gas regulator, flex hose & quick-disconnect (3/4", 1" or 1-1/4").
- Stainless steel common front rail for battery line-ups up to 102".
- End caps & covers for standalone installation.
