Garland M47-23S Master Gas Ranges

Garland Master Series 34" Heavy-Duty Gas Range with 23" Griddle & 2 Open Burners

Built for high-volume, all-day service, the Garland Master Series combination top range pairs a full-size griddle with powerful open burners in a compact 34 inch footprint, while its integrated storage base keeps essential cookware within arm’s reach.

Performance & Construction Highlights

• (2) 24,000 BTU Starfire open burners for instant, responsive heat.
• 23" manual-control griddle with 1" (25 mm) thick steel plate for superior heat retention.
• Total input: 104,000 BTU/h — plenty of power for peak-time production.
• Stainless steel front, sides and 7-1/2" (191 mm) deep front rail stand up to daily abuse and wipe clean fast.
• One-piece stainless drip tray plus front-mounted grease drawer speed up end-of-shift cleanup.
• Removable cast-iron ring grates over each burner for durability and easy access to components.
• 6" (152 mm) adjustable chrome-steel legs provide a leveled, 36" working height.
• Spacious enclosed storage base for pans, sheet trays and utensils.
• Clip-on stainless backsplash and welded side/rear splashguards contain splatter and improve safety.
• Large, easy-grip gas valves deliver precise flame control and long service life.
• Factory-supplied 1-1/4" NPT front gas manifold with pressure regulator; optional rear connection available.
• NSF & CSA certified for commercial kitchens.

Technical Specifications

Gas ratings shown are for installations up to 2,000 ft (610 m) above sea level. Specify altitude if higher. Dimensions and weights are approximate and subject to change.
