Garland M44S Master Gas Ranges
Description
Garland Master Series 34" Heavy-Duty Gas Range
Model M44S | 140,000 BTU Total InputGive your line the legendary power of Garland’s Master Series without paying for an oven you don’t need. The 34 inch M44S couples four 35,000 BTU Starfire® open burners with a full-width storage base—perfect for kitchens that demand exceptional output, rugged construction and fast, easy cleanup.
Performance Highlights
- Four 35,000 BTU (10.25 kW) Starfire® burners for instant searing and pinpoint simmering.
- Two-piece, lift-off burner heads speed up deep cleaning.
- Heavy cast-iron top grates and removable ring bowls stand up to continuous duty.
- Full-width, one-piece stainless-steel drip tray makes crumb & grease removal effortless.
- 7-1/2" (191 mm) stainless front rail adds plating space and protects the valve panel.
- Aluminized-steel storage cabinet keeps hotel pans, stock pots or smallwares close by.
- 6" (152 mm) chrome-plated adjustable legs for quick leveling.
- Piezo spark ignition on pilots—no matches required.
Built to Master Series Standards
- Stainless-steel front & sides resist corrosion and wipe clean fast.
- Front 1-1/4" NPT gas manifold with capped right/left end for easy suite line-up.
- Field-convertible for Natural or LP gas; regulator supplied.
- CSA Flame, CSA Star & NSF listed for open-kitchen safety and sanitation.
Technical Specifications
| Overall width | 34" / 864 mm |
|---|---|
| Overall depth (to rail) | 38" / 965 mm |
| Work height (with NSF legs) | 36-3/8" / 924 mm |
| Burners | 4 Starfire open burners, 35,000 BTU each |
| Total input | 140,000 BTU/hr (Natural) | 128,000 BTU/hr (Propane) |
| Operating pressure | Natural 6" WC | Propane 10" WC |
| Gas connection | Front 1-1/4" NPT (standard) | Optional rear 3/4" or 1" |
| Storage base interior (W × D × H) | 26" × 30-1/2" × 20-1/2" (660 × 773 × 519 mm) |
| Shipping weight | Approx. 340 lb / 155 kg |
| Agency approvals | CSA Flame, CSA Star, NSF |
Optional Upgrades & Accessories
- 10", 17" or 33" stainless-steel backguards (required—select to match width).
- Single or double tubular high shelves.
- Rear gas connection kits (3/4" or 1").
- Quick-disconnect hose set with restraining device.
- Polyurethane locking casters (non-marking).
- Common front rail for battery configurations up to 102".
- Stainless-steel storage shelf (replaces standard aluminized shelf).
NOTE: Master Series units supplied with casters must be secured with an approved restraining device.
Installation clearances—combustible surfaces: sides 14" (356 mm), back 6" (152 mm).
