Garland M42T Master Gas Ranges
Description
Garland Master Series 34″ Modular Heavy-Duty Combination Range Top
2 Starfire™ Open Burners • 17″ Steel-Plate Griddle • 103,000 BTU (Natural)Built for chefs who refuse to compromise, the Garland Master Series modular combination top delivers the raw power of two 35,000 BTU Starfire™ burners and the menu-expanding versatility of a 17″ griddle in one rugged, space-saving unit. Drop it onto a refrigerated base, equipment stand or custom chef’s counter and unleash true heavy-duty production in even the tightest cooklines.
Why You’ll Love It
- Starfire™ Power: Two 35,000 BTU open burners with removable heads for simple, thorough cleaning.
- Precision Griddling: 17″ W × 25″ D, 1″ thick steel plate heated by a 33,000 BTU “H” burner and Hi-Lo valve for exact temperature control.
- All-Stainless Exterior: Front and sides resist dents, scratches and daily wear while wiping down fast.
- Built-in Protection: 2-5/16″ welded splash guards plus a clip-on stainless backsplash keep grease where it belongs.
- Front-Mounted Grease Drawer: Large, removable pan slides out for quick emptying between rushes.
- Heavy Cast-Iron Grates & Ring Grates: Stand up to repeated high-heat cycling and accept stock pots up to 14″.
- Field-Configurable Gas: Natural or LP operation; factory-installed 1 ¼″ front gas connection.
- Certified Safe & Sanitary: CSA Flame, CSA Star and NSF listings.
Technical Specs
| Model | M42T (modular top) |
|---|---|
| Total Gas Input | 103,000 BTU/hr Natural | 97,000 BTU/hr LP |
| Open Burners | 2 × 35,000 BTU Starfire™ (removable heads) |
| Griddle Section | 17″ W × 25″ D, 1″ thick steel plate, 33,000 BTU “H” burner |
| Dimensions (W × D × H) | 34″ × 38″ × 9.5″ (864 × 965 × 241 mm) (with supplied stand) |
| Gas Connection | 1 ¼″ NPT front (rear optional) |
| Clearances (Combustible) | 11″ sides | 6″ back |
| Certifications | CSA Flame, CSA Star, NSF |
| Shipping Weight | Approx. 330 lb (150 kg) |
Popular Factory Options
- Fully grooved griddle plate
- Stainless steel common front rail (for battery line-ups)
- Rear gas connection (¾″, 1″ or 1 ¼″ NPT)
- Gas flex hose & quick-disconnect kit (5′)
- Stainless steel backguard or single/double deck high shelf
- Set of four non-marking swivel casters with brakes
Need a matching base, convection oven or battery line-up? Call 1-800-424-2411 and our Garland specialists will configure the perfect Master Series suite for your kitchen.
