Garland GN17R80 Arctic Fire Undercounter & Worktop Refrigeration
Description
Garland Arctic Fire 80" Remote Refrigerated Base – 3-Section / 6-Drawer
Model GN17R80 | Compatible with Garland Master Series Modular CooktopsBring your mise en place directly to the cookline. The Garland Arctic Fire remote refrigerated base keeps up to eight full-size hotel pans at food-safe temperatures while fitting neatly beneath your Master Series range battery—so chefs can grab, cook and serve without breaking stride.
Key Features
- 80" wide, three-section cabinet with six self-closing drawers
- Remote refrigeration – connect to a customer-supplied condensing unit (R-404A)
- Durable stainless steel exterior front & sides; galvanized bottom & back
- ABS interior sides with stainless steel interior top, rear & bottom for easy cleaning
- Center-mounted, flush pull handles stay cool and snag-free
- Heavy-duty stainless steel drawer slides with stainless steel bearings; removable track assemblies carry a 10-year parts warranty
- Santoprene magnetic gaskets provide a tight, tool-free seal
- 6" (152 mm) adjustable stainless steel legs
- Face-mounted analog thermometer for quick temperature checks
Drawer Capacity
| Total drawers | 6 (2 per section) |
|---|---|
| Pan capacity | Holds up to 8 full-size 12" × 20" × 4" hotel pans (GN 1/1, 100 mm deep) |
| Drawer layout* | Two 19" pairs & one 27" pair |
*Factory configuration for model GN17R80.
Why Remote Refrigeration?
- No compressor heat or noise under the line—better kitchen comfort & lower hood load
- Easier service access and routine cleaning
- Lets you match condensing unit size to your exact ambient conditions
Ideal For
- High-volume restaurants that need refrigerated ingredients within arm’s reach
- Hotels, resorts and institutions running large Garland Master Series cooklines
- Kitchens looking to maximise hood and floor space without sacrificing cold storage
Specifications
| Model | GN17R80 |
|---|---|
| Cabinet width | 80" (2032 mm) |
| Cabinet depth | 34" (864 mm) |
| Cabinet height | 27" (686 mm) to work surface |
| Sections / drawers | 3 sections / 6 drawers |
| Refrigerant | R-404A (remote system – compressor by others) |
| Electrical | 115 V / 60 Hz / 1-ph, 1.5 A (hard-wired) |
| BTU load | 675 BTU/hr (recommended 1/5 HP remote compressor) |
| Legs | 6" (152 mm) stainless steel, adjustable |
| Construction | Stainless steel exterior; ABS & stainless interior; galvanized bottom & back |
Garland equipment is intended for commercial use only.
