Garland Arctic Fire™ 46" Self-Contained Refrigerated Base
Model GN17C46 | 1-Section | 2 Drawers | 115 VPut perfectly chilled ingredients right where the action is. The Garland Arctic Fire GN17C46 slides beneath your Heavy-Duty Master Series cooktop to deliver dependable, low-profile cold storage without sacrificing valuable line space.
Key Benefits
- Compact 46 in. footprint and 27 in. height fit under Garland Master Series modular tops*
- Tropicalized, self-contained refrigeration system rated for 100 °F (38 °C) kitchens
- Two self-closing drawers with flush, center-mounted pulls—no protruding hardware
- Each drawer holds one 12 × 20 × 4 in. hotel pan (GN 1/1, 100 mm)
- Heavy-duty stainless-steel roller tracks with a 10-year parts warranty
- 1/5 HP compressor • 270 BTU/hr • R-404A refrigerant
- Front-mounted dial thermometer for at-a-glance temperature checks
- Durable stainless-steel exterior and 6 in. adjustable legs; optional casters available
- Santoprene magnetic gaskets snap tight and remove easily for cleaning
Technical Specifications
| Model | GN17C46 (North America) |
|---|---|
| Exterior dimensions (W × D × H) | 46 in. × 34 in. × 27 in. (1,168 × 864 × 686 mm) |
| Configuration | 1 section | 2 self-closing drawers |
| Pan capacity | 2 × full-size 12 × 20 × 4 in. hotel pans |
| Interior volume | 40 ft³ |
| Compressor | 1/5 HP, right-side mounted |
| Refrigerant | R-404A |
| BTU/hr | 270 |
| Electrical | 115 V / 60 Hz / 1φ, 8 A, NEMA 5-15P cord & plug |
| Legs | 6 in. stainless steel, adjustable (casters optional) |
| Crated weight | 340 lb (154 kg) |
| Certifications | cULus, NSF |
Rock-Solid Warranty
- 5-year replacement parts warranty on the compressor (first year parts & labor)
- 10-year parts warranty on stainless-steel drawer roller assemblies
Commercial use only: Arctic Fire refrigerated bases are engineered exclusively for Garland Master Series modular cooktops and are not approved for residential applications.
*Unit must be ordered in the same transaction as a Garland Master Series modular cooktop. Contact us for information on optional casters, extra-deep drawers, or step-down charbroiler configurations.
$15,000.15
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Garland Arctic Fire 46" undercounter refrigerator base with 2 self-closing drawers, durable stainless steel, self-contained cooling, 115V reliability.
Manufacturer
Garland
Brand name
Arctic Fire
Height
27.0in
Width
46.0in
Depth
34.0in
Shipping Weight
340.0lbs
Top Finish
stainless steel top
Exterior Finish
all stainless steel exterior
Drawer Qty
2 drawers
Compressor HP
1/5 HP
Width
37" - 48" wide
Refrigeration
self-contained, side mounted
Specifications
Arctic Fire Refrigerator Base, self-contained refrigeration, 46" W, one-section, (2) self-closing drawers with center pull handles, stainless steel exterior, 6" stainless steel legs (available only when ordered with Master Series modular cook tops) 115/60/1-ph, 8.2 amps (Garland)
