Garland

Garland GIR36-CUISINE MOUNT Garland Cuisine Salamander Broilers

SKU: GIR36-CUISINE MOUNT
$4,058.55
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Charbroilers & Grills Commercial Ranges Garland New Arrivals Restaurant Equipment Salamander Broilers Salamander Broilers

Garland Cuisine Series Infra-Red Salamander Broiler – 36" Range-Mount, 40,000 BTU

Model UIR36 | NSF Listed | For Garland 36" Cuisine Series Ranges

Give every dish a perfect finish with the Garland Cuisine Series UIR36 salamander broiler. Designed to mount directly above your 36" Garland Cuisine heavy-duty range, this compact powerhouse delivers intense, even infrared heat for rapid browning, caramelizing, melting and holding — all within arm’s reach of the cooking line.

Key Features & Benefits

  • Dual 20,000 BTU atmospheric infrared burners (40,000 BTU total) provide instant, even heat.
  • Independent Hi-Lo valve controls for precise heat management on each burner zone.
  • Spring-balanced rack with three adjustable positions (2 ¾", 3 ½", 4 ⅜" from cook surface) to handle everything from delicate gratins to thick chops.
  • Large, removable grease pan keeps the work area clean and simplifies end-of-shift maintenance.
  • All-stainless-steel exterior (top, front, sides, backsplash & bottom) with integrated heat shields stands up to the harshest commercial kitchens.
  • Factory-supplied ½" NPT top gas inlet & regulator; natural or propane configuration available.
  • Shipped ready to mount on Garland Cuisine Series 36" ranges — no field fabrication required.
  • NSF listed and CSA certified for gas safety.
  • Backed by a 1-year limited parts & labor warranty (USA & Canada).

Technical Specifications

Model UIR36 (Cuisine Series Range-Mount)
Overall Width 35 ½" / 900 mm
Overall Depth 18" / 457 mm
Overall Height 15" / 381 mm (add 4" / 102 mm if top gas inlet extension is used)
Total Heat Input 40,000 BTU /hr (11.7 kW) – 2 × 20,000 BTU infrared burners
Gas Type Natural (6" WC) or Propane (10" WC) – specify when ordering
Gas Connection ½" NPT top inlet (rear inlet optional)
Rack Positions 3 (spring-balanced)
Construction Stainless steel top, front, sides, backsplash & bottom with heat shields
Shipping Weight 200 lb / 91 kg (crated)
Certifications NSF, CSA (US & Canada)
Warranty 1-year limited parts & labor

Perfect For

  • Caramelizing crème brûlée or meringues
  • Finishing au gratin potatoes and mac & cheese
  • Melting cheese on sandwiches, burgers & nachos
  • Holding steaks and chops at serving temperature without overcooking

Supplied for left-side installation on 36" Cuisine Series ranges. Right-side mounting available on 60" ranges (special order). Maintain minimum clearances of 6" (152 mm) at sides and rear.

Commercial use only: Garland salamander broilers are engineered and certified for professional kitchens. They are not approved for residential installation or service.

Overall Dimensions:

35.5"W x 18.0"D x 15.0"H

Product Weight:

200.0 lb
Manufacturer Garland
Brand name Garland Cuisine
Certifications ["NSF"]
Height 15.0in
Width 35.5in
Depth 18.0in
Shipping Weight 200.0lbs
Type infrared
Width (side - side) 32" - 36"
Specifications Cuisine Series Salamander Broiler, gas, 35-1/2" W, for 36" Restaurant Range, (2) 20,000 BTU infrared burners with Hi-Lo valve controls each, (3) position spring balanced rack assembly, removable grease pan, stainless steel top, front, sides, backsplash & bottom with heat shields, (price with range order), 40,000 BTU, NSF (U S Range)

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download PDF Check list PDF Download PDF Owner's manual PDF Download
