Garland 36ES39 36E Series Electric Ranges
Description
Garland 36E Series 36" Heavy-Duty Electric Boil Section Range — Model 36ES39
Six-zone boiling plate top with built-in storage baseBuilt for relentless, high-volume service, the Garland 36ES39 combines rugged construction with the precision of electric heat. Six individually controlled boil sections let your team keep stocks, sauces and sides rolling without juggling burners, while the spacious storage base saves valuable rack space elsewhere in the kitchen. Stainless steel everywhere you touch it, NSF and cCSAus certifications, and straightforward three-heat switch controls make this range a dependable cornerstone for any commercial cookline.
Standard features- Six-section boiling plate top • each 11 3⁄4 in. zone has its own three-heat switch for low / medium / high control
- Total connected load: 12 kW • fast, even heat with zero open flame
- 3 in. (76 mm) stainless steel vent riser protects the backsplash and aids airflow
- All-stainless front, sides and 8 in. deep front rail for quick, sanitary wipe-downs
- Full storage base (no oven) keeps sheet pans, smallwares or dry goods within arm’s reach
- 6 in. (152 mm) adjustable chrome-plated legs • NSF-approved and simple to level
- Factory-installed circuit breakers / fuses safeguard internal components
- cCSAus & NSF listed for U.S. and Canadian installations
- 1-year limited parts & labor warranty (USA & Canada)
| Total connected load | 12 kW |
|---|---|
| Single-phase amp draw | 208 V – 58 A | 240 V – 51 A | 460 V – 26 A |
| Three-phase amp draw (per line) |
208 V – 34 A / 34 A / 34 A 240 V – 30 A / 30 A / 30 A 460 V – 15 A / 15 A / 15 A |
| Electrical connection | Rear • 6 in. (152 mm) from floor |
| Overall width | 36 in. / 914 mm |
|---|---|
| Overall depth (incl. rail) | 33 3⁄4 in. / 857 mm |
| Work height | 36 in. / 914 mm to cooking surface |
| Vent riser height | +3 in. / 76 mm |
| Combustible clearances | Sides – 3 in. (76 mm) | Rear – 1⁄2 in. (13 mm) |
- Stainless steel main back panel
- Polyurethane non-marking swivel casters with front brakes
- 6 in. adjustable stainless steel legs
- Marine package — hand rails, door latch, drip-tray stop and deck fasteners
- High-voltage 460 V version (three heat switches instead of six)
Garland equipment is engineered for commercial food-service use only and is not intended for residential installation.
