Garland  |  36E Series  |  SKU: 36ES38

Garland 36ES38 36E Series Electric Ranges

$10,417.00
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Cutsheet Cutsheet
Related Searches
Commercial Ranges Electric Ranges Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Garland 36E Series – 36" Electric Heavy-Duty Griddle Range with Storage Base

Model 36ES38 • 15 kW • cCSAus & NSF Certified

Bring high-output griddling and convenient under-counter storage to your cookline in one rugged, space-saving footprint. The Garland 36E Series combines a 36-inch, three-zone electric griddle with a full-width open base, giving chefs easy access to pans, utensils and prep equipment while delivering the power and precision you expect from Garland.

Key Features

  • One-piece 36" (914 mm) griddle plate with 3 independent thermostats for zone control 100–450 °F (38–232 °C).
  • 15 kW total connected load – field-wired for 208 V, 240 V or 460 V, single- or three-phase service.
  • Open storage base in lieu of an oven keeps essential cookware within arm’s reach.
  • Durable stainless steel front, sides, front rail & 3" (76 mm) vent riser stand up to daily high-volume use.
  • Front & rear stainless steel grease troughs simplify cleanup and promote a safer work station.
  • Individual circuit breakers/fuses provide built-in electrical protection.
  • 6" (152 mm) adjustable chrome-plated legs for easy leveling and floor sanitation.
  • Meets cCSAus and NSF standards; backed by a 1-year parts & labor warranty (USA & Canada).

Specifications

Model 36ES38
Griddle width 36" / 914 mm
Heat zones 3 – thermostatically controlled
Temperature range 100–450 °F (38–232 °C)
Total power 15 kW
Voltage options 208 V, 240 V or 460 V • single- or three-phase
Nominal amps (1-phase) 72 A @ 208 V  •  64 A @ 240 V  •  33 A @ 460 V
Nominal amps/line (3-phase) 42 A @ 208 V  •  37 A @ 240 V  •  19 A @ 460 V
Overall dimensions (W × D × H) 36" x 33-3/4" x 36-1/4" (914 x 857 x 921 mm)
Clearances – combustible 3" sides  •  1/2" rear
Certifications cCSAus, NSF
Warranty 1 year parts & labor (USA & Canada)

Popular Options & Accessories

  • Stainless steel main back panel
  • Set of four non-marking swivel casters with front brakes (unit must be restrained per local code)
  • 6" (152 mm) adjustable stainless steel legs
  • High-voltage 460 V configuration
  • Marine package: hand rails, door latch, drip-tray stop & deck fasteners
Commercial use only: Garland equipment is engineered for professional kitchens and is not intended for residential installation.

Features & Specs

Manufacturer

Garland

Brand_name

36E Series

Certifications

NSF, cCSAus

Height

37.38in

Width

36.0in

Depth

33.75in

Shipping Weight

550.0lbs

Base

cabinet(s)

Top

(1) griddle

Vent

backriser

Exterior Finish

stainless steel front & sides

Specifications

36E Series Heavy Duty Range, electric, 36" griddle, thermostatic controls, storage base, 3" high vent riser, stainless steel front, sides & front rail, 6" legs, 15.0kW, cCSAus, NSF (Garland)
