Follett F1811CU Air-cooled, three phase remote condenser for use with D1811R evaporator unit. Pre-charged, R449a
$11,447.37
/each
Ships in 11–14 business days
- Product type
- Air-cooled remote condenser
- Compatible evaporator
- D1811R
- Electrical
- 208-230 V/60 Hz/3 phase
- Operating power
- 3.6 kW
- Refrigerant
- R449a
- Factory refrigerant charge
- 16.5 lb
Specifications
Product type
Air-cooled remote condenser
Compatible evaporator
D1811R
Electrical
208-230 V/60 Hz/3 phase
Operating power
3.6 kW
Refrigerant
R449a
Factory refrigerant charge
16.5 lb
Minimum circuit ampacity
16.7 A
Maximum circuit HVACR breaker size
25 A
Maximum refrigerant line run
75 ft (22.9 m)
Maximum line rise above evaporator
35 ft (10.7 m)
Maximum evaporator mounting above condenser
15 ft (4.6 m)
Maximum refrigeration line drop without oil trap
15 ft (4.6 m)
Outdoor operating temperature
-20 to 120°F (-29 to 49°C)
Approximate shipping weight
300 lb (136 kg)
Description
The Follett F1811CU is an air-cooled, three-phase remote condenser for use with the D1811R evaporator unit. It is factory pre-charged with 16.5 lb of R449a refrigerant.
- 208-230 V/60 Hz/3-phase electrical configuration
- 3.6 kW operating power
- 75 ft (22.9 m) maximum refrigerant line run
- 30.00 in wide by 38.50 in deep by 25.75 in high
Overall Dimensions:
30.0"W x 38.5"D x 25.75"HProduct Weight:
300.0 lbAir-cooled remote condenser
Designed for use with the D1811R evaporator unit.
Three-phase electrical service
Uses 208-230 V at 60 Hz and three-phase power.
Factory pre-charged refrigerant
Supplied with a factory charge of 16.5 lb of R449a.
Extended refrigerant line run
Supports a maximum refrigerant line run of 75 ft (22.9 m).
Outdoor operating range
The specified outdoor condensing unit operating range is -20 to 120°F (-29 to 49°C).
Installation elevation limits
The maximum line rise above the evaporator is 35 ft (10.7 m), and the evaporator may be mounted up to 15 ft (4.6 m) above the condenser.
Documentation
Certifications & Compliance
Frequently Asked Questions
The F1811CU is an air-cooled, three-phase remote condenser for use with the D1811R evaporator unit.
Yes. It is factory pre-charged with 16.5 lb of R449a refrigerant.
The electrical specification is 208-230 V/60 Hz/3 phase.
The unit is 30.00 in wide, 38.50 in deep, and 25.75 in high.
The maximum refrigerant line run is 75 ft (22.9 m).
