Follett Products, LLC (Middleby)

Follett Products, LLC (Middleby) Horizon Elite F1412CU Remote 3-Phase Outdoor Condensing Unit, Not Pre-Charged

SKU: F1412CU
$3,702.00
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Horizon Elite F1412CU is a remote three-phase outdoor condensing unit for use with Horizon Elite D1412R series ice machines. The unit is supplied not pre-charged.

  • 208–230 V, 60 Hz, three-phase electrical service
  • Maximum refrigerant line run of 100 ft
  • Outdoor operating range from -20°F to 120°F
  • 39.6 in wide, 28.2 in deep and 26.0 in high

Overall Dimensions:

39.6"W x 28.2"D x 26.0"H

Product Weight:

282.0 lb

D1412R series compatibility

Designed for use with Horizon Elite D1412R series ice machines.

Three-phase electrical service

Operates at 208–230 V, 60 Hz, three phase.

Outdoor installation

Specified for outdoor condensing unit operation.

Extended line routing

Supports a maximum refrigerant line run of 100 ft.

Not pre-charged

The unit is specified as not pre-charged.

Outdoor operating range

Specified operating air temperature range is -20°F to 120°F.

Related Searches

Best Sellers Follett Products, LLC (Middleby) Ice Machine, Bin & Dispenser Replacement Parts Ice Machines & Handling Ice Maker Parts & Accessories Ice-System Replacement Parts New Arrivals Refrigeration & Ice Restaurant Equipment Restaurant Equipment Parts
Product type Remote outdoor condensing unit
Compatible ice machine Horizon Elite D1412R series
Electrical 208–230 V, 60 Hz, 3 phase
Operating power 3.0 kW
Minimum circuit ampacity 12 A
Maximum overcurrent protection 20 A
Outdoor operating temperature -20°F to 120°F
Maximum refrigerant line run 100 ft
Maximum line rise above evaporator 35 ft
Maximum evaporator height above condenser 15 ft
Maximum line drop without oil trap 15 ft
Refrigerant charge Not pre-charged
Heat rejection 14,000 BTU/hr

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed
Certified badge of NSF Certified
NSF Certified

Warranty & Protection

3 years parts and labor; 5 years compressor parts.

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Middleby financial flyer PDF Download

Frequently Asked Questions

The F1412CU is for use with Horizon Elite D1412R series ice machines.
No. The F1412CU is specified as not pre-charged.
The specified electrical service is 208–230 V, 60 Hz, three phase.
The unit is 39.6 in wide, 28.2 in deep and 26.0 in high.
The maximum refrigerant line run is 100 ft.
The specified outdoor operating air temperature range is -20°F to 120°F.
