Follett C2112CU Air-cooled, single phase remote condenser for use with D2112R evaporator unit. Pre-charged, R449a
- Product type
- Air-cooled remote condenser
- Compatible evaporator unit
- D2112R
- Refrigerant
- R449a
- Factory refrigerant charge
- 11 lb, pre-charged
- Electrical service
- 208-230 V / 60 Hz / 1 ph
- Operating power
- 2.53 kW
Specifications
Description
The Follett C2112CU is an air-cooled, single-phase remote condenser for use with the D2112R evaporator unit. It is factory pre-charged with R449a and operates on 208-230 V, 60 Hz, single-phase power.
- Refrigerant: 11 lb of pre-charged R449a
- Operating power: 2.53 kW
- Dimensions: 40 in W x 34 in D x 36.5 in H
- Electrical protection: 23 A minimum circuit ampacity and 35 A maximum HVACR breaker size
- Certifications: NSF, ETL and cUL Energy Verified
Overall Dimensions:
40.0"W x 34.0"D x 36.5"HProduct Weight:
285.0 lbAir-cooled remote condenser
The C2112CU is an air-cooled remote condenser for the D2112R evaporator unit.
D2112R compatibility
The model is specified for use with the D2112R evaporator unit.
Pre-charged R449a refrigerant
The unit is pre-charged at the factory with 11 lb of R449a.
Single-phase electrical service
Electrical service is 208-230 V, 60 Hz, single phase.
Refrigeration line limits
The maximum refrigerant line run is 75 ft (22.9 m), with a maximum line rise above the evaporator of 35 ft (10.7 m). The evaporator may be mounted up to 15 ft (4.6 m) above the condenser, and the maximum line drop without an oil trap is 15 ft (4.6 m).
Outdoor operating range
The specified outdoor condensing unit operating limits are -20°F to 120°F (-29°C to 49°C) ambient air temperature.
Electrical circuit requirements
The unit has a 23 A minimum circuit ampacity and a 35 A maximum HVACR breaker size.
Physical dimensions
The condenser measures 40 in wide, 34 in deep and 36.5 in high.
