Follett C1012CU Air-cooled, single phase remote condenser for use with D1012R evaporator unit. Pre-charged, R449a
- Product type
- Air-cooled remote condenser
- Compatible evaporator
- D1012R
- Electrical
- 208–230 V/60 Hz/1 ph
- Refrigerant
- R449a
- Factory refrigerant charge
- 8 lb, pre-charged at factory
- Operating power
- 1.30 kW
Specifications
Description
C1012CU is an air-cooled, single-phase remote condenser for use with the Follett D1012R evaporator unit. It is factory pre-charged with R449a and uses 208–230 V, 60 Hz, single-phase electrical service.
- Operating power: 1.30 kW
- Maximum refrigerant line run: 75 ft (22.9 m)
- Factory refrigerant charge: 8 lb of R449a
Overall Dimensions:
40.0"W x 34.0"D x 25.25"HProduct Weight:
280.0 lbAir-cooled remote condenser
Provides air-cooled remote condensing for the D1012R evaporator unit.
Single-phase electrical service
Specified for 208–230 V, 60 Hz, single-phase operation.
Factory-precharged refrigerant system
Pre-charged at the factory with 8 lb of R449a.
Remote installation range
Supports a maximum refrigerant line run of 75 ft (22.9 m).
Outdoor operating limits
Specified operating air temperature range is -20 to 120 °F (-29 to 49 °C).
Installation elevation limits
The maximum line rise above the evaporator is 35 ft (10.7 m), and the evaporator may be mounted up to 15 ft (4.6 m) above the condenser.
