Play manufacturer video for Fisher 28231 Wall-Mounted Reel Rinse Installation KitThe Fisher 28231 is a wall-mounted reel rinse installation kit with wall and riser control valves, an anti-spill vacuum breaker, and an adjustable wall bracket.
- Wall bracket adjusts from 2 inches to 12 inches.
- Wall control valve includes internal spring-loaded check valves and swiveling seat disks.
- Vacuum breaker has an anti-spill design and is ASSE 1056 approved.
- System limits are 40°F to 140°F maximum temperature and 200 PSI maximum static pressure.
Product Weight:
15.0 lbWall control valve
Includes adjustable eccentrics from 7-1/2 inches to 8-1/2 inches, internal spring-loaded check valves, swiveling seat disks, stainless steel seats, stainless steel seat screws, and stainless steel handle screws.
Riser control valve
Has a right-hand swivel stem with cross handle, stainless steel seat, stainless steel seat screw, and stainless steel handle screw.
Vacuum breaker
Features an anti-spill design and is ASSE 1056 approved.
Adjustable wall bracket
Adjusts from 2 inches to 12 inches.
Connection details
The cutsheet specifies a 1/2 inch NPT male outlet and a 1/2 inch NPT female rough-in. It also notes that 1/2 inch NPT male nipples are not included.
System limits
Maximum temperature is 140°F within a stated 40°F to 140°F range, and maximum static pressure is 200 PSI.
