Play manufacturer video for Fisher DrainKing 22322 Twist Waste Valve with Flat Strainer and Overflow Body, 3-1/2 in Sink Opening, 1-1/2 or 2 in Drain OutletFisher DrainKing 22322 Twist Waste Valve with Flat Strainer and Overflow Body, 3-1/2 in Sink Opening, 1-1/2 or 2 in Drain Outlet
SKU: 22322
$216.86
/each
Enter ZIP for a shipping estimate
Expected delivery to by
Estimated Arrival
Estimated Cost
Finalize delivery options at checkout
The Fisher DrainKing 22322 is a twist waste valve with a stainless steel flat strainer and 14 x 16 in. overflow tube and elbow configuration.
- Sink opening: 3-1/2 in.
- Drain outlet: 1-1/2 in. or 2 in.
- Drain rate: 12 GPM.
- Construction: Cast red brass body with stainless steel components.
- Operation: A 1/4-turn movement fully opens and closes the valve.
Product Weight:
10.0 lbFlat strainer
Stainless steel flat strainer is part of the waste valve configuration.
Overflow configuration
Configured with a 14 x 16 in. overflow tube and elbow.
Cast red brass body
The valve body is made of cast red brass.
Dual Teflon seals
Uses dual Teflon seals.
Stainless steel ball
Includes a stainless steel ball.
Stainless steel clamping ring
Uses a stainless steel clamping ring.
Clear-through opening
The clear-through opening does not require disassembly when snaking is required.
Sealing angle
The industry-standard sealing angle fits flush to standard stainless steel sinks.
Quarter-turn operation
A 1/4 turn fully opens and closes the valve.
Drain rate
Rated at 12 GPM.
Type
Twist waste valve
Sink opening size
3-1/2 in.
Drain outlet size
1-1/2 in. or 2 in.
Drain outlet connection
2 in. NPT male and 1-1/2 in. NPT female
Overflow configuration
14 x 16 in. tube and elbow
Drain rate
12 GPM
Body material
Cast red brass
Strainer material
Stainless steel
Ball material
Stainless steel
Seal configuration
Dual Teflon seals
Valve operation
1/4 turn
Referenced standard
ANSI/A112.18.1M
Weight
10 lb.
Documents
Frequently Asked Questions
It is specified for a 3-1/2 in. sink opening.
The product is specified with a 1-1/2 in. or 2 in. drain outlet; the connections are 2 in. NPT male and 1-1/2 in. NPT female.
The drain rate is 12 GPM.
A 1/4 turn fully opens and closes the valve.
