Firex (Middleby)

Firex (Middleby) Figaro UDFIE40A-D_V2 Multifunctional Electric Cooker, 41 gal, Stainless Steel

SKU: UDFIE40A-D_V2
$41,184.00
Free Shipping
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Firex Figaro UDFIE40A-D_V2 is a 41-gallon electric multifunctional cooker with an AISI 304 stainless steel cooking vessel, motorized insulated lid, and capacitive 7-inch touchscreen.

  • Construction: AISI 304 stainless steel cooking vessel, AISI 430 stainless steel frame, AISI 304 stainless steel outer cover, and adjustable stainless steel feet.
  • Control: Six-probe temperature control, manual and program cooking modes, automatic lid opening and closing, and step-by-step operating instructions.
  • Operation: Integrated shower head, automatic tank tilting and return, and a basket lifting system identified as an accessory.
  • Safety: Emergency button, resettable safety thermostat, pressure safety valve, and lid-opening prevention while pressure remains in the tank.
  • Data connection: USB connection for HACCP data downloads and software updates.

Overall Dimensions:

65.12"W x 37.81"D x 45.31"H

Product Weight:

860.0 lb

Stainless steel construction

The cooking vessel is AISI 304 stainless steel, with an AISI 430 stainless steel frame and AISI 304 stainless steel outer cover.

Motorized insulated lid

The AISI 304 lid includes a food-grade silicone sealing gasket and automatic opening and closing.

Pressure cooking clamping

A 4-point motorized clamping system supports pressure cooking.

Touchscreen controls

A capacitive 7-inch touchscreen provides manual and program cooking modes, cooking settings, tank control, and operating instructions.

Six-probe temperature control

Temperature control is specified with six probes.

Integrated shower head

An integrated shower head is included in the cooker design.

Basket lifting system

A basket lifting system is listed as an accessory.

Safety systems

Safety equipment includes an emergency button, resettable safety thermostat, pressure safety valve, and prevention of lid opening while the tank is pressurized.

HACCP data connection

The USB connection supports HACCP data downloads and software updates.

Related Searches

Best Sellers Braising Pans & Tilt Skillets Braising Pans & Tilt Skillets Commercial Food Processor Parts Cooking Equipment Equipment Firex (Middleby) Food Prep Equipment Parts New Arrivals Restaurant Equipment Restaurant Equipment Parts Specialty Cooking Equipment
Capacity 41 gal
Cooking vessel Stainless steel AISI 304
Frame Stainless steel AISI 430
Outer cover Stainless steel AISI 304
Controls Capacitive 7 in touch screen
Temperature control 6 probes
Lid Motorized and insulated, with automatic opening and closing
Clamping system 4-point motorized system
Heating Thick-film heating elements in direct contact with the tank bottom
Integrated shower head Yes
Basket lifting system Accessory
Protection level IPX5
Water inlets Cold and hot water, 3/4 in connections
Electrical requirements 220-240 V, 60 Hz, 3-phase, 38.5 kW, 100 A; or 208 V, 60 Hz, 3-phase, 32 kW, 110 A; or optional 460-480 V, 60 Hz, 3-phase, 40.5 kW, 57 A

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The cooker has a 41-gallon capacity.
It uses a capacitive 7-inch touchscreen with manual and program cooking modes.
Yes. It has a 4-point motorized clamping system for pressure cooking, a pressure safety valve, and prevention of lid opening while pressure remains in the tank.
The listed configurations are 220-240 V, 60 Hz, 3-phase at 38.5 kW and 100 A; 208 V, 60 Hz, 3-phase at 32 kW and 110 A; or optional 460-480 V, 60 Hz, 3-phase at 40.5 kW and 57 A.
The data sheet identifies the basket lifting system as an accessory and does not establish that it is included.
