Key specifications

Amps
6.2 Amps
Phase
1-Phase
Dimensions
99.0"W × 33.0"D × 40.0"H
Type
Worktop Refrigerator
Style
Low Boy
Installation Type
Undercounter
Spec sheet
EMI Industries SKU: LBD9933S

EMI Industries LBD9933S 99-Inch 6-Door Worktop Refrigerator

$39,735.60
/each
Estimated to ship in 16–19 business days
Width
Electrical115 V · 1-phase · 60 Hz · 6.2 A
Compressor location
Cutting board
Compressor housing fixture
Top edge

Need something else? Contact us.

Included: EMI Industries warranty One-year warranty against defects in workmanship and material

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $3,676/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Specifications

Type Worktop Refrigerator
Style Low Boy
Installation Type Undercounter
Material Stainless Steel
Finish Stainless Steel
Interior Finish Stainless Steel
Width 99 Inches
Depth 33 Inches
Height 40 Inches
Pan Size 12 x 20 Inches
Pan Capacity 12 Pans
Refrigeration Type Self-Contained, Side-Mounted
Refrigerant Type R448A
Controls Digital Thermostat and Display
Compressor Horsepower 1/3 HP
Voltage 115 Volts
Amps 6.2 Amps
Hertz 60 Hz
Phase 1-Phase
Cord Length 6 Feet
Plug Type NEMA 5-15P
Leg Diameter 2 Inches
Leg Adjustment 6 to 8 Inches

Description

The EMI Industries LBD9933S is a 99-inch undercounter low boy worktop refrigerator with self-contained, side-mounted refrigeration.

  • Measures 99 inches wide, 33 inches deep, and 40 inches high.
  • Provides capacity for twelve 12 x 20-inch pans.
  • Includes a digital thermostat and display with R448A refrigerant.
  • Uses a 115-volt, 6.2-amp, single-phase electrical connection with a 6-foot cord and NEMA 5-15P plug.
  • Features a stainless steel worktop, front panel, interior, and legs.

Overall Dimensions:

99.0"W x 33.0"D x 40.0"H

Product Weight:

615.0 lb

Self-Contained Refrigeration

The refrigeration system is self-contained and mounted at the side.

Stainless Steel Surfaces

The worktop, front panel, interior, and legs are stainless steel.

Pan Capacity

Specification data lists capacity for twelve 12 x 20-inch pans.

Digital Controls

Includes a digital thermostat and display.

Electrical Connection

Rated at 115 Volts, 6.2 Amps, 60 Hz, and 1-Phase with a 6-foot cord and NEMA 5-15P plug.

Adjustable Legs

Includes 2-inch-diameter stainless steel legs adjustable from 6 to 8 inches.

Compressor

Uses a 1/3 HP compressor.

Frequently Asked Questions

The product measures 99 inches wide, 33 inches deep, and 40 inches high.
It uses self-contained, side-mounted refrigeration with R448A refrigerant.
The specification data lists capacity for twelve 12 x 20-inch pans.
It is rated at 115 Volts, 6.2 Amps, 60 Hz, and 1-Phase, with a 6-foot cord and NEMA 5-15P plug.
The warranty covers defects in workmanship and material for one year. Refrigeration coverage includes one year of parts and labor and a five-year prorated compressor warranty, subject to stated exclusions.

This ships by freight truck on a pallet, not by a parcel carrier. The carrier calls ahead to set a delivery window, and an adult 18 or older must be there to receive, inspect and sign for it.

The driver brings it to the back of the truck, or lowers it to the ground with liftgate service. They don’t bring it inside, so plan for a pallet jack or two people to move it from the curb.

What to have ready on delivery day

  • Count every piece against the delivery receipt.
  • Check every side for crushed corners, torn wrap, punctures, water stains or a tipped unit.
  • Photograph the freight on the truck before it’s moved.
  • If you see any damage, even cosmetic, write “DAMAGED” and what you see on the receipt before you sign.

Your shipping email has the exact instructions for your order. Questions at the door? Call us at (888) 307-5030.

How to inspect and sign for freight

Keep all the packaging, photograph the damage and the packaging, and tell us within 5 business days of delivery. Reply to your shipping email with the photos or call (888) 307-5030.

If the driver won’t wait while you inspect, write “Received – pending inspection. Driver would not wait.” with the date and time on the receipt, then inspect right away and report any damage within 24 hours.

Reporting damage after delivery

Book your installer only after the carrier gives you a firm delivery appointment. Freight dates can move, and installer trips lost to a late truck aren’t reimbursable.
