The EMI Industries LBD7233S is a 72-inch low boy worktop refrigerator with four 27-inch, 20-gauge stainless steel doors and self-contained, side-mounted refrigeration.

It features a 300 series stainless steel top and front panel, digital thermostat and display, adjustable stainless steel legs, and an 115 V electrical connection. The exact-model specification lists capacity for eight 12 x 20 pans; pans are not included.

  • 72 in. wide by 33 in. deep by 40 in. high
  • Four 27 in., 20-gauge stainless steel doors
  • 1/4 HP refrigeration system using R-448A refrigerant
  • 6 ft. cord with NEMA 5-15P plug
  • ENERGY STAR, ETL, and NSF listings

Overall Dimensions:

72.0"W x 33.0"D x 40.0"H

Product Weight:

480.0 lb

Stainless steel worktop

The unit has a 300 series stainless steel top and front panel; the cutsheet specifies a 14-gauge Type 300 stainless steel top with a 6 in. backsplash.

Four stainless steel access sections

The exact-model specification lists four 27 in., 20-gauge stainless steel doors, while the catalog access attribute identifies the access type as drawers.

Self-contained refrigeration

The refrigeration system is self-contained and side-mounted.

Digital temperature control

A digital thermostat and display are included.

Pan capacity

The exact-model specification lists capacity for eight 12 x 20 pans. Pans are not included.

Adjustable stainless steel legs

The unit uses 2 in. diameter stainless steel legs adjustable from 6 to 8 in.

Electrical connection

The refrigerator is rated at 115 V, 60 Hz, single phase, with 4.8 A draw, a 6 ft. cord, and a NEMA 5-15P plug.

Certified listings

Supported listings are ENERGY STAR, ETL, and NSF.

Product Type Low boy worktop refrigerator
Overall Width 72 in.
Overall Depth 33 in.
Overall Height 40 in.
Access Type Drawers
Door Configuration 4 x 27 in. 20-gauge stainless steel doors
Pan Drawer Capacity 8 x 12 x 20 in. pans
Worktop Material 300 series stainless steel; 14-gauge Type 300 top
Front Panel Material 300 series stainless steel
Backsplash Height 6 in.
Refrigeration Self-contained, side-mounted
Thermostat Digital thermostat and display
Refrigerant R-448A
Compressor Power 1/4 HP
Current Draw 4.8 A
Electrical 115 V/60 Hz/1 phase
Cord Length 6 ft.
Plug Type NEMA 5-15P
Legs 2 in. diameter stainless steel legs, adjustable from 6 to 8 in.
Energy Efficiency ENERGY STAR
Product Weight 480 lb

Certifications & Compliance

Certified badge of Energy Star Certified
Energy Star Certified
Certified badge of ETL Listed
ETL Listed
Certified badge of NSF Certified
NSF Certified

Warranty & Protection

One-year warranty against defects in workmanship and material from the date of purchase; refrigeration includes one year of parts and labor coverage and a five-year prorated compressor warranty.

Documents

PDF Cutsheet PDF Download PDF Warranty PDF Download

Frequently Asked Questions

The unit measures 72 in. wide by 33 in. deep by 40 in. high.
The exact-model specification lists four 27 in., 20-gauge stainless steel doors.
It uses a self-contained, side-mounted refrigeration system with R-448A refrigerant.
The unit requires 115 V, 60 Hz, single-phase power and draws 4.8 A. It includes a 6 ft. cord with a NEMA 5-15P plug.
The exact-model specification lists capacity for eight 12 x 20 pans. Pans are not included.
EMI Industries provides a one-year warranty against defects in workmanship and material from the date of purchase. Refrigeration coverage is one year for parts and labor, with a five-year prorated compressor warranty.
