Eagle Group Spec-Master FN Series Coved Corner Two-Compartment Sink with 24-Inch Right Drainboard

69-1/2 Inch Wide x 35 Inch Deep x 44-1/2 Inch High, 14-Gauge 300 Series Stainless Steel

Built for busy prep areas, this heavy-duty two-compartment sink combines a right-hand drainboard, coved corners, and a wall-protecting backsplash for efficient cleanup.

  • Two 20" W x 28" front-to-back x 14" deep compartments support wash and rinse tasks.
  • 24" right-hand drainboard adds staging and drying space.
  • 14-gauge 300 series stainless steel top is designed for demanding commercial use.
  • 9-1/2" backsplash with 1" upturn and tile edge helps protect the wall.
  • Includes 3-1/2" basket drains and 8" on-center faucet holes.
  • Stainless steel legs, all-side crossbracing, and adjustable bullet feet improve stability.

Overall Dimensions:

69.5"W x 35.0"D x 44.5"H

Product Weight:

248.0 lb

Two-Compartment Sink

Provides separate bowls for washing and rinsing in one compact work station.

Two-Compartment Sink

24-Inch Right Drainboard

Integrated right-hand drainboard offers a convenient landing area and positive drainage.

14-Gauge 300 Series Stainless Steel Top

Heavy-duty stainless steel construction is built for long service life in commercial settings.

Coved Corner Bowls

Full 3/8-inch radius corners help reduce buildup and make cleaning easier.

9-1/2-Inch Backsplash

Backsplash includes a 1-inch upturn and tile edge to help protect the wall behind the sink.

8-Inch On-Center Faucet Holes

Pre-punched splash-mount faucet holes simplify installation.

Rolled Front and Side Edges

Rolled rims provide a cleaner finished look and safer handling edges.

Reinforced Stainless Base

Stainless steel legs with all-side crossbracing and adjustable bullet feet add stability.

Includes Basket Drains

Supplied with 3-1/2-inch basket-type waste drains.

One-Piece Seamless Assembly

Fuse-welded, planished construction creates a smooth, sanitary sink unit.

Type Two-Compartment Sink
Style Coved Corner
Installation Type Floor Model (With Legs)
Material Stainless Steel
Top Stainless Series 300 Series Stainless Steel
Finish Satin
Top Gauge 14 Gauge
Compartments 2
Compartment Width 20 Inches
Compartment Length 28 Inches
Compartment Depth 14 Inches
Drainboard Width 24 Inches
Backsplash Height 9-1/2 Inches
Faucet Hole Diameter 1-1/8 Inches
Faucet Hole Spacing 8 Inches On Center
Shipping Width 70 Inches
Shipping Depth 35 Inches
Shipping Height 45 Inches
Shipping Weight 248 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Warranty & Protection

1-year limited warranty from original installation, not to exceed 18 months from shipment.

Documents

PDF Cutsheet PDF Download PDF Brochure PDF Download PDF Care & maintenance PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

Each compartment measures 20 inches wide x 28 inches front-to-back x 14 inches deep.
Yes. It includes 3-1/2-inch basket-type waste drains.
The backsplash has 1-1/8-inch faucet holes punched on 8-inch centers.
This model has a 24-inch right-hand drainboard.
It carries a 1-year limited warranty from the date of original installation, not to exceed 18 months from the shipment date.
