Eagle Spec-Master FN Series Coved Corner Four-Compartment Sink with 36-Inch Right Drainboard, 109-1/2 Inch W x 27 Inch D, 14 Gauge Stainless Steel
Eagle Spec-Master FN Series Coved Corner Four-Compartment Sink with 36-Inch Right Drainboard, 109-1/2 Inch W x 27 Inch D, 14 Gauge Stainless Steel
9-1/2 Inch Backsplash, 14-Inch Deep Compartments, Stainless Steel Legs
Built for high-volume wash stations, this four-compartment sink combines a 36-inch right drainboard with heavy-duty stainless steel construction for dependable daily use.
- Four-compartment sink with a 36-inch right-hand drainboard for efficient wash and dry workflow.
- 14 gauge 300 series stainless steel top and stainless steel construction for commercial durability.
- Coved corners, rolled edges, and seamless welded assembly make cleaning easier.
- 9-1/2-inch backsplash with 1-inch upturn and tile edge helps protect the wall.
- Includes 3-1/2-inch basket drains and two sets of 8-inch OC splash-mount faucet holes.
- Stainless steel legs, crossbracing, and adjustable bullet feet provide stable support.
Overall Dimensions:
109.5"W x 27.0"D x 44.5"HProduct Weight:
392.0 lb14 Gauge 300 Series Stainless Steel Construction
Top, drainboards, backsplash, and rolled rims are built from 14 gauge 300 series stainless steel for durability and corrosion resistance.
Four Coved Corner Compartments
Four sink bowls feature full 3/4-inch radius coved corners and seamless welding for easier cleaning.
Right-Hand 36-Inch Drainboard
The right-side drainboard is integrally welded and V-creased for positive drainage.
9-1/2-Inch Backsplash
Backsplash includes a 1-inch upturn and tile edge to help protect walls from splash and spills.
Splash-Mount Faucet Holes
Two sets of 1-1/8-inch faucet holes are punched on 8-inch centers.
Heavy-Duty Stainless Steel Base
Stainless steel legs with gussets, crossbracing on all sides, and adjustable bullet feet provide strength and stability.
3-1/2-Inch Basket Drains
Includes basket-type waste drains with 1-1/2-inch outlets.
Fuse-Welded One-Piece Assembly
The entire unit is fuse-welded and planished, with bullnosed outside corners and a satin-finish blend.
Certifications & Compliance
Warranty & Protection
1 year from original installation, not to exceed 18 months from shipment.
