Eagle Group ASWTFT-1584-SG Anti-Splash Cool Trough Water Tempering System with Grated Floor Drain

84" Wide, 15" Deep, 14 Gauge Stainless Steel, Mechanical Temp Sensor

Ensure safe and code-compliant water tempering for your floor drain with this durable, anti-splash stainless steel trough system.

  • Integrated mechanical temperature sensor requires no electrical connection.
  • Constructed from robust 14/304 stainless steel for lasting durability.
  • Features a built-in pitch and removable perforated basket for efficient drainage.
  • Includes essential plumbing components: shutoff valve and two pressure check valves.
  • Designed for recessed floor installation, ideal for commercial environments.
  • NSF certified for sanitation and public health standards.

Overall Dimensions:

84.0"W x 15.0"D x 15.25"H

Anti-Splash Cool Trough Design

Specifically engineered to temper water and prevent splashing, enhancing safety and cleanliness around floor drains.

Grated Floor Drain

Equipped with a stainless steel subway-style grating and removable perforated basket to capture debris and ensure proper drainage.

Integral Mechanical Temperature Sensor

Monitors and tempers water temperature without requiring any electrical connection, simplifying installation and operation.

Built-in Pitch to Drain

The trough floor is designed with an integral pitch towards the 4-inch drain, promoting efficient water evacuation.

14/304 Stainless Steel Construction

Manufactured from heavy-duty 14 gauge, Type 304 stainless steel for superior corrosion resistance and longevity in demanding commercial settings.

Included Plumbing Valves

Comes with a shutoff valve and two pressure check valves, providing necessary controls and safety features for the water system.

Recessed Installation Ready

Designed for flush installation into a recessed concrete slab, providing a seamless and permanent floor drainage solution.

Removable Perforated Basket

Catches solids and debris, preventing drain clogs and simplifying cleaning.

Type Anti-Splash Cool Trough
Style Floor Drain System
Installation Type Drop-In
Material 14/304 Stainless Steel
Interior Finish Stainless Steel
Grate Type Subway-style grating
Grate Construction Stainless Steel
Pan Type Anti-Splash
Pan Depth 4 Inches
Trough Construction 14 Gauge Stainless Steel
Controls Mechanical Temperature Sensor
Drain Connection Size 4 Inches
Water Connection Size 1 Inch
Water Connection Required
Drain Connection Required
Shipping Width 84 Inches
Shipping Depth 15 Inches
Shipping Height 16 Inches
Shipping Weight null
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Warranty & Protection

1-year parts and labor limited warranty

Documents

PDF Cutsheet PDF Download PDF Instructions PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

This system is designed for recessed installation into a concrete slab, with floor clips to secure it, providing a flush and permanent floor drainage solution.
No, the system features an integral mechanical temperature sensor that does not require an electrical connection, simplifying installation and operation.
It requires a 1-inch water line and connects to a 4-inch drain. An RPZ (Reduced Pressure Zone) valve, supplied by Eagle, must also be installed by a plumbing contractor.
The backflow preventer (RPZ valve) must be tested periodically in compliance with local codes, but at least once per year, to ensure proper function and safety.
The trough and access compartment are constructed from heavy-duty 14 gauge, Type 304 stainless steel, with stainless steel subway-style grating for durability and corrosion resistance.
Yes, the system includes a removable perforated basket located within the drain to effectively catch solids and debris, preventing clogs and simplifying cleaning.
