Eagle Group 314 Series Commercial 1-Compartment 304 Stainless Steel Sink with Left Drainboard, 38-7/8" W x 27-1/2" D

SKU: 314-16-1-18L-X
$1,202.67
/each
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

1-compartment Sinks Best Sellers Commercial Plumbing Supplies Commercial Sinks Compartment Sinks Eagle Group New Arrivals Restaurant Equipment Sinks & Handwashing Stations

Eagle Group 314 Series Commercial 1-Compartment 304 Stainless Steel Sink with Left Drainboard, 38-7/8" W x 27-1/2" D

16" x 20" x 13-1/2" Bowl, 9-1/2" Backsplash, Adjustable Bullet Feet

This durable one-compartment sink pairs a 304 stainless steel top with a left drainboard, high backsplash, and stable galvanized leg base for efficient commercial wash stations.

  • One 16" x 20" x 13-1/2" compartment with an 18" left drainboard for prep and cleanup space.
  • 304 stainless steel construction with coved corners for durability and easier cleaning.
  • 9-1/2" backsplash with 1" upturn and tile edge helps protect the wall from splashes.
  • 8" O.C. splash-mount faucet holes and an included 3-1/2" basket drain support easy installation.
  • Galvanized legs with side crossrails and adjustable plastic bullet feet provide stable support.
  • NSF-listed construction is suited for commercial sanitation requirements.

Overall Dimensions:

38.88"W x 27.5"D x 44.0"H

Product Weight:

96.0 lb

304 Stainless Steel Construction

Durable, corrosion-resistant top and bowl built for commercial use.

304 Stainless Steel Construction

Single 16" x 20" Bowl

One compartment sized for wash-up, prep, and cleanup tasks.

18" Left Drainboard

Provides extra landing and drainage space on the left side.

9-1/2" Backsplash

Includes a 1" upturn and tile edge to help protect the wall.

Splash-Mount Faucet Holes

8" on-center holes accept a standard splash-mounted faucet.

Coved Corners

Rounded corners help simplify cleaning and maintenance.

Euro-Style Front And Side Edges

2" edges provide a finished, professional appearance.

Galvanized Leg Base

Legs and side crossrails provide sturdy support; bullet feet adjust for leveling.

Includes Basket Drain

Comes with a 3-1/2" basket drain.

NSF-Listed

Designed to meet NSF sanitation requirements for commercial kitchen use.

Type Sink
Style 1-Compartment Sink
Installation Type Floor Model
Material 304 Stainless Steel
Interior Finish 304 Stainless Steel
Base Construction Galvanized Steel
Base Type Legs With Side Crossrails
Compartments 1
Drainboard Side Left
Drainboard Length 18 Inches
Compartment Width 16 Inches
Compartment Depth 20 Inches
Sink Depth 13-1/2 Inches
Backsplash Height 9-1/2 Inches
Faucet Hole Spacing 8 Inches O.C.
Shipping Width 39 Inches
Shipping Depth 28 Inches
Shipping Height 44 Inches
Shipping Weight 96 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Warranty & Protection

1 year from original installation, not to exceed 18 months from shipment.

Documents

PDF Cutsheet PDF Download PDF Installation sheet PDF Download PDF Brochure 2 PDF Download PDF Brochure 1 PDF Download PDF Care & maintenance PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

No. The installation sheet says faucet(s) are provided separately and installed through the 8" O.C. splash-mount holes.
The product description says it includes a 3-1/2" basket drain.
The bowl measures 16" wide x 20" front-to-back x 13-1/2" deep.
It uses adjustable plastic bullet feet on the legs.
Fill the set-screw heads with NSF-approved sealant and seal the backsplash to the wall or cover the top flange with finished wall.
Rinse after detergents and sanitizers, avoid chlorine/bleach and steel wool, and wipe with a damp cloth between cleanings.
