Dormont ReliaGuard 1 Inch I.D. x 36 Inch Single SwivelGuard Gas Connector Kit with Quick Disconnect and Restraining Cable

Gray PVC-Coated Stainless Steel, For Moveable Equipment

Built for moveable commercial equipment, this connector kit combines 360° rotational fittings, thermal shutoff protection, and a restraining cable to help reduce wear and improve safety.

  • 1 inch inside diameter and 36 inch length for moveable gas appliance hookups.
  • 304 stainless steel tubing and stainless steel braid provide flexibility and durability.
  • Gray PVC coating resists flame and withstands temperatures up to 350°F.
  • Standard Snap quick disconnect automatically shuts off gas above 350°F.
  • SwivelGuard rotational fittings help reduce connector stress and allow closer wall placement.
  • Includes PVC-coated restraining cable and mounting hardware to help prevent strain transfer.
  • Limited 5-year warranty for the original appliance connection.

Overall Dimensions:

10.38"W x 2.88"D x 26.63"H

Product Weight:

8.8 lb

360° Rotational End Fittings

Rotational fittings at both ends help reduce stress on the connector and improve flexibility.

Standard Snap Quick Disconnect

Includes a quick-disconnect fitting with thermal shutoff when internal temperature exceeds 350°F.

304 Stainless Steel Tubing

Annealed, corrugated 304 stainless steel tubing provides durable, flexible gas service.

Stainless Steel Wire Braid

Multi-strand stainless steel braid helps protect the corrugations as equipment is moved.

Gray PVC Coating

Flame-resistant coating melts at 350°F and will not hold a flame.

Restraining Cable and Hardware Included

PVC-coated steel restraining cable and mounting hardware are included to help prevent strain on the connector.

Designed for Moveable Equipment

Intended for caster-mounted commercial cooking equipment and other moveable gas appliances.

Maximum Operating Pressure

Rated for a maximum operating pressure of 1/2 psi.

Indoor Use Only

The connector is specified for indoor use only and should not be used below 32°F (0°C).

5-Year Limited Warranty

Warranty coverage is stated for 5 years from the original appliance to which the connector is connected.

Type Gas Connector Kit
Style Moveable Grade
Gas Connection Size 1 Inch Inside Diameter
Length 36 Inches
Material 304 Stainless Steel
Finish Gray PVC Coating
BTU 353,000 BTU/hr
Shipping Width 11 Inches
Shipping Depth 3 Inches
Shipping Height 27 Inches
Shipping Weight 8.8 lb.
Selling Unit Each
Units Per Case 1

Warranty & Protection

Limited 5-year warranty.

Documents

PDF Cutsheet PDF Download PDF Brochure PDF Download

Frequently Asked Questions

It has a 1 inch inside diameter and is 36 inches long.
Yes, it includes a Standard Snap quick-disconnect assembly.
Yes, the kit includes a PVC-coated restraining cable and mounting hardware.
It includes a thermal shutoff quick disconnect, flame-resistant gray PVC coating, and rotational end fittings that reduce stress on the connector.
It is designed for moveable, caster-mounted commercial cooking equipment.
The product includes a limited 5-year warranty from the original appliance connection.
