Delfield

Delfield N8787-DESP Steam Tables & Food Wells

SKU: N8787-DESP
$9,461.50
/each
Discontinued
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Delfield New Arrivals

Delfield N8787-DESP ESP 6-Pan Drop-In Hot Food Well

Energy-Saving Power | Individual Digital Controls | Wet or Dry Operation

Serve hot entrées, sides, and toppings with precision and efficiency. The N8787-DESP is Delfield’s largest Energy Saving Power (ESP) drop-in well, giving you six individually-heated 12" × 20" pans in one low-wattage, high-performance package that installs flush in any 86-1/4" counter cutout.

Why You’ll Love It

  • Six independent 500 W heat pads deliver even, responsive heat to each well.
  • Digital temperature controllers (one per well) arrive pre-wired to a single remote panel with 4 ft of conduit—mount it where it’s most convenient.
  • True wet or dry flexibility; run dry for maximum energy savings or add water to boost humidity throughout a service rush.
  • 1/2" drains in every well are factory-manifolded to one gate valve for fast, mess-free cleanup.
  • 18-gauge stainless-steel top and 20-gauge drawn wells for a seamless, food-safe surface that wipes clean.
  • 1" fiberglass insulation on all sides and between wells keeps heat where it belongs while protecting surrounding counters.
  • Galvanized exterior housing adds strength without extra weight.
  • Press-fit perimeter gasket is pre-installed—simply drop it in and hard-wire.

Quick Specs

Pan Capacity 6 × 12" × 20" full-size pans (flush mount)
Counter Cutout Required 86.25" W × 25.00" D (219 cm × 64 cm)
Well Interior (each) 11.87" W × 19.87" D × 6.25" H (30 cm × 50 cm × 16 cm)
Voltage / Phase 208-230 V, 60 Hz, 1-phase (240 V optional)
Total Watts / Amps 3000 W  |  14.4-16.2 A (12.6 A @ 240 V)
Ship Weight 236 lb (107 kg)
Construction 18-ga stainless top, 20-ga stainless wells, galvanized exterior
Drain 6 × 0.5" NPT drains manifolded to single 0.5" gate valve (left-hand)
Controls 6 independent solid-state digital thermostats, remote panel

Installation Notes

  • Unit ships ready to hard-wire; cord & plug are not supplied.
  • Provide 3" clearance between the exterior body and any combustible material.
  • Control panel requires a 5.00" H × 33.88" W × 7.50" D cutout.
Electrical Safety: This equipment must be installed by a qualified electrician in accordance with local codes and the National Electrical Code (NEC).

Certifications & Warranty

  • UL, NSF, cUL, and CE listed.
  • 1-year parts & labor warranty backed by Delfield’s nationwide service network.

Need adapter bars, autofill, or FlexiShield™ breath guards? Contact us for factory-approved options and lead times.

Overall Dimensions:

87.24"W x 26.0"D x 9.5"H

Product Weight:

236.0 lb
Manufacturer Delfield
Certifications ["NSF", "CE", "UL"]
Height 9.5in
Width 87.24in
Depth 26.0in
Shipping Weight 236.0lbs
Style individual pans
Controls digital controls
Wet or Dry operation wet or dry
Pan Capacity (6) full size (12" x 20")
Drain with drain
Construction stainless steel top, corrosion resistant steel exterior
Insulated or Non-Insulated insulated
Specifications Drop-In Hot Food Well Unit, Electric, individual pans, wet/dry type with drain & manifold, 6-pan size for 12" x 20" pan, individual digital temperature controls, stainless steel top & wells, galvanized exterior body, (86-1/4" x 25" cutout required), UL, NSF, cUL, CE

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified
