Delfield  |  SKU: N8773-DESP

Delfield N8773-DESP Steam Tables & Food Wells

$8,172.50
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Service manual Brochure Warranty sheet
Related Searches
Delfield Food Bars & Buffets Food Holding & Warming Equipment Food Wells & Serving Lines Hot Well Restaurant Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Delfield N8773-DESP ESP 5-Well Drop-In Hot Food Unit

Energy-Saving Power wells with independent digital control

Hold five full-size pans of entrées, sides or sauces at precise serving temperature without wasting energy or counter space. Delfield’s low-watt ESP technology teams up with individually controlled heat pads to deliver unbeatable food quality and utility savings in a single 72 in. drop-in module.

Key Features

  • 5 individual 12" × 20" wells – operate wet or dry as your menu demands
  • Energy-efficient 500 W heat pad on every well (2,500 W total)
  • Solid-state digital thermostat for each well, pre-wired to a remote panel (4' conduit included)
  • 18-ga stainless steel top with die-stamped, flush-mount wells; depressed edge retains condensation
  • 6.25" deep, 20-ga stainless wells fully insulated with 1" fiberglass
  • 1/2" stainless drains on every well, manifolded to a left-hand gate valve for quick, safe draining
  • Non-marring press-fit perimeter gasket for fast, caulk-free installation
  • Rugged 20-ga galvanized exterior body built for life below the counter
  • UL, cUL, NSF & CE listed for electrical safety and sanitation
  • 1-year parts & labor warranty backed by Delfield

Technical Specifications

Model N8773-DESP
Pan Capacity 5 × full-size (12" × 20") pans
Counter Cutout 72.37" W × 25.00" D   (184 cm × 64 cm)
Well Depth 6.25" (16 cm)
Overall Depth Below Counter 7.83" (20 cm)
Control Panel Cutout 5.00" H × 28.38" W × 7.50" D
Electrical 208-230 V / 60 Hz / 1 Ph   |   2,500 W   |   12–13.5 A
Optional 240 V 60 Hz: 10.5 A
Connection Hard-wired, 3-wire junction box (field)
Drain 1/2" NPT manifold with gate valve
Ship Weight ≈ 186 lb (84 kg)

A minimum 3" (76 mm) clearance is required between the unit body and any combustible materials. Installation must comply with all applicable electrical and plumbing codes.

Popular Options & Accessories (sold separately)

  • Fill faucet or AutoFill system
  • Adapter plates & bars for fractional pans
  • Single- or double-service flip-up sneeze guards
  • Telescoping covers
  • 240 V / 50 Hz or 3-phase wiring
Important: This unit is shipped without a cord and plug. All electrical connections must be made by a qualified electrician at the time of installation.

Features & Specs

Manufacturer

Delfield

Certifications

NSF, CE, UL

Height

9.5in

Width

73.37in

Depth

26.0in

Shipping Weight

186.0lbs

Controls

digital controls

Pan Capacity

(5) full size (12" x 20")

Insulated or Non-Insulated

insulated

Style

individual pans

Wet or Dry operation

wet or dry

Construction

stainless steel top, corrosion resistant steel exterior

Drain

with drain

Specifications

Drop-In Hot Food Well Unit, Electric, individual pans, wet/dry type with drain & manifold, 5-pan size for 12" x 20" pan, individual digital temperature controls, stainless steel top & wells, galvanized exterior body, (72-3/8" x 25" cutout required), UL, NSF, cUL, CE
