Delfield N8745-DESP Steam Tables & Food Wells
Description
Delfield N8745-DESP Drop-In ESP Hot Food Well – 3 x 12" × 20"
Energy-saving performance, precise digital control, effortless installationKeep entrées, sides and sauces at NSF-safe serving temperatures without wasting energy. The Delfield N8745-DESP features three individually-heated wells, each equipped with its own 500 W heat pad and digital control, giving you the flexibility to run any combination of wet or dry holding—all in one compact drop-in module.
Key features you’ll love
- Three full-size (12" × 20") flush-mount wells for seamless counter presentation.
- Individual solid-state digital temperature controllers—fine-tune each well independently.
- Energy Saving Power (ESP) design: only 500 W per well for lower utility costs.
- Wet or dry operation with ½" stainless steel drains; all drains manifold to one gate valve for fast clean-up.
- 18-gauge stainless steel top & 20-gauge drawn wells withstand daily commercial use.
- 1" fiberglass insulation on sides, bottom and between wells keeps heat where it belongs.
- Pre-installed non-marring perimeter gasket for a true “drop-in and go” installation.
- Galvanized exterior body for long-lasting corrosion resistance beneath the counter line.
- Remote control panel ships pre-wired with 4' conduit—mount where staff can reach, not customers.
- Field-hard-wired junction box (three-wire) for a clean, code-compliant hook-up.
Why choose ESP (Energy Saving Power) technology?
- Up to 25 % lower wattage vs. traditional tubular elements.
- Fast heat-up with even distribution across the well bottom & sides—no hot spots.
- Run dry for maximum energy savings or wet when humidity is required.
Specifications
| Model | N8745-DESP |
|---|---|
| Pan capacity | 3 × 12" × 20" (full-size) pans, 6.25" well depth |
| Cut-out required | 44 5/8" W × 25" D (113 cm × 64 cm) |
| Control panel cut-out | 5" H × 17 3/8" W × 7 1/2" D (mount remotely) |
| Electrical | 208–230 V / 60 Hz / 1 Ph, 1 500 W, 7.2–8.1 A Optional 240 V / 50 Hz available |
| Heat power | 3 × 500 W heat pads (one per well) |
| Drain connection | ½" NPT female (manifolded to single gate valve) |
| Shipping weight | Approx. 134 lb (61 kg) |
| Clearance | Minimum 3" between unit exterior and combustible surfaces |
Quick installation tips
- Unit ships with press-fit gasket already in place—no messy silicone required.
- Hard-wire connection must be performed by a qualified electrician.
- Mount the supplied control panel in an ergonomic location within 4' of the well.
Need extras? Factory options include autofill, fill faucet, adapter bars, telescoping covers, 3-phase wiring and more—contact us for a customised quote.
Safety, compliance & warranty
- Certified: UL, cUL, NSF, CE—meets international electrical & sanitation standards.
- One-year parts & labour warranty backed by Delfield’s nationwide service network.
