Delfield  |  SKU: N8731-DESP

Delfield N8731-DESP Steam Tables & Food Wells

$3,534.50
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Brochure Service manual Warranty sheet
Related Searches
Delfield Food Bars & Buffets Food Holding & Warming Equipment Food Wells & Serving Lines Hot Well Restaurant Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Delfield N8731-DESP 2-Pan ESP Drop-In Hot Food Well

Energy-Saving • Individual Digital Controls • Wet or Dry Operation

Give every entrée the perfect hold with Delfield’s low-watt Energy Saving Power (ESP) hot wells. The N8731-DESP drops neatly into a 30-3/4″ × 25″ counter cutout and delivers precise, individually-controlled heat to two 12″ × 20″ hotel pans—without soaking up excess energy or space.

Why You’ll Love It

  • Dual 12″ × 20″ wells—accommodates two full-size pans in a compact footprint.
  • 500 W heat pad per well provides fast, even heating with up to 49 % energy savings versus coil systems.
  • Individual digital temperature controls (remote panel included, 4 ft conduit) for pinpoint accuracy.
  • Wet or dry operation—run dry for maximum efficiency or add water for extra humidity.
  • Built-in drain & manifold with a ½″ gate valve makes cleanup quick and sanitary.
  • 18-ga stainless steel top & 20-ga wells resist corrosion and wipe clean in seconds.
  • Fully insulated with 1″ fiberglass on all sides and between wells to keep heat where it belongs.
  • Press-fit perimeter gasket arrives installed—just drop it in and secure.
  • Certified safe: UL, NSF, cUL, CE.
  • Backed by a 1-year parts & labor warranty.

Technical Specifications

Capacity 2 individual wells (12″ × 20″ pans)
Counter Cutout Required 30.75″ W × 25.00″ D (781 mm × 635 mm)
Well Depth 6.25″ (159 mm)
Voltage / Phase / Hertz 208–230 V / 1 Ph / 60 Hz
Total Wattage 1,000 W (500 W per well)
Running Amps 4.8 A @ 208 V  |  5.4 A @ 230 V
Optional 240 V Draw 4.2 A
Drain Connection ½″ F-NPT per well, manifolded to single ½″ gate valve (left side)
Control Panel Cutout 5.00″ H × 11.88″ W × 7.50″ D
Exterior Housing 20-ga galvanized steel
Shipping Weight 99 lb (45 kg)
Certifications UL, NSF, cUL, CE

Popular Options & Accessories (sold separately)

  • Fill or autofill faucet kits
  • Adapter bars & plates for fractional pans
  • Single- or double-service flip-up sneeze guards
  • Telescoping lids or covers
  • 3-phase or 240 V/50 Hz electrical packages
  • Omit drains/manifold for special applications
Installation Note: Unit ships without cord or plug and must be hard-wired by a licensed electrician. Maintain a minimum 3″ clearance between the exterior body and combustible materials.

Specifications subject to change without notice. Always consult the installation manual and local codes prior to ordering or installation.

Features & Specs

Manufacturer

Delfield

Certifications

NSF, CE, UL

Height

9.5in

Width

31.76in

Depth

26.0in

Shipping Weight

99.0lbs

Controls

digital controls

Pan Capacity

(2) full size (12" x 20")

Style

individual pans

Wet or Dry operation

wet or dry

Construction

stainless steel top, corrosion resistant steel exterior

Insulated or Non-Insulated

insulated

Drain

with drain

Specifications

Drop-In Hot Food Well Unit, Electric, individual pans, wet/dry type with drain & manifold, 2-pan size for 12" x 20" pan, individual digital temperature controls, stainless steel top & wells, galvanized exterior body, (30-3/4" x 25" cutout required), UL, NSF, cUL, CE
