Delfield N8669P Steam Tables & Food Wells
Description
Delfield N8669P 69" Drop-In Hot & Cold Combination Food Well
Five-pan well · Self-contained refrigeration · Flip-a-switch flexibilityServe today’s menu exactly the way you need—piping hot at lunch, perfectly chilled for dinner—without changing equipment or sacrificing counter space. The Delfield N8669P combines a powerful refrigerated cold pan with an in-well stainless steel immersion heater, letting you toggle between full NSF-4 hot or NSF-7 cold operation in seconds.
Key advantages
- Dual-mode design: three-way Hot / Cold / Off switch on remote control panel
- Holds five full-size 12" × 20" pans (adaptor bars included)
- 8" deep single stainless steel tank with 1" drain & screen for fast clean-up
- Adjustable pan support: flush-mount for hot service, 2" recessed for cold
- Energy-efficient GreenGenius™ R290 refrigeration, 1/4 HP hermetic compressor
- Electronic cold-side thermostat; high-limit safety on immersion heater
- Rugged construction: one-piece stainless steel top & liner, galvanized exterior housing
- Pre-installed push-in flange gasket & stainless louver for true “drop-in and go” installation
- cULus, UL, NSF-listed for both hot and cold operation
- Backed by Delfield’s 1-year parts & labor warranty
Technical specifications
| Model | N8669P |
|---|---|
| Overall length | 69 in (175.3 cm) |
| Counter cutout required | 68 in × 25 in (173 cm × 64 cm) |
| Pan capacity | 5 × 12 in × 20 in full-size pans, up to 6 in deep |
| Well depth | 8 in (20.3 cm) |
| Refrigerant | R290, 3.5 oz charge |
| Compressor | 1/4 HP, self-contained |
| Electrical | 120-240 V / 60 Hz / 1-ph, 42 A (field-wired) |
| BTU load (design) | 1,137 BTU/hr |
| Shipping weight | 266 lb (121 kg) |
| Certifications | cULus, UL, NSF, R290 |
Included with the unit
- Remote control panel with three-way selector & adjustable hot thermostat
- 5 stainless steel adaptor bars for full-size pans
- Factory-installed perimeter gasket
- Stainless steel louver for condenser air intake
Need additional adaptor bars, automatic water fill, or compressor relocation? Delfield offers a wide range of factory options—contact us for details.
