Delfield N8030 Drop-In Ice-Cooled Cold Pan – 30 3/4″ W x 26″ D
2-Pan Capacity • Stainless Steel • NSF-2 ListedKeep salads, toppings and chilled sides crisp and appetising without the noise, heat or energy draw of mechanical refrigeration. The Delfield N8030 drop-in ice-cooled cold pan nests neatly into a 29 3/4″ x 25″ counter cut-out, delivering reliable cold holding for two full-size food pans—perfect for buffets, prep lines and grab-and-go service.
Key Features
- Holds (2) standard 12″ x 20″ pans – adapter bars included for a level, secure fit.
- 20-gauge stainless steel top with non-marring press-fit gasket protects counters and creates a flush, built-in look.
- 22-gauge stainless steel interior with V-stamped pan rest for efficient ice melt drainage.
- Sectional, removable perforated false bottom keeps product above melt-water for maximum freshness.
- High-density, Kyoto Protocol compliant polyurethane insulation – Non-ODP, Non-GWP.
- 1″ plastic drain (field installed) for quick, hassle-free clean-up.
- Durable 24-gauge galvanized exterior stands up to busy commercial kitchens.
- NSF-2 certified for safe, sanitary cold holding.
At-a-Glance Specs
| Model | Delfield N8030 |
|---|---|
| Pan Capacity | (2) 12″ x 20″ full-size pans (pans not included) |
| Overall Dimensions | 30.75″ W x 26″ D |
| Required Cut-Out | 29.75″ W x 25″ D |
| Interior Depth | ≈ 9.35″ |
| Drain Size | 1″ diameter (plastic, supplied) |
| Construction | 20-ga SS top / 22-ga SS liner / 24-ga galvanized exterior |
| Insulation | CFC-free, high-density polyurethane foam |
| Shipping Weight | 100 lb / 45 kg (approx.) |
| Certifications | NSF-2 |
| Warranty | 1 year parts & 90 days labor |
Ideal For
- Salad or sandwich prep stations
- Self-service buffets & cafeterias
- Grab-and-go merchandisers
- Catering or action stations
Looking for a different length or a matching sneeze guard? Delfield offers custom sizes and accessories—ask us for details.
$1,862.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Delfield N8030 drop-in ice-cooled cold pan: stainless interior, insulated, removable false bottom, 1" drain, NSF — durable, easy-clean 30.75" unit.
Manufacturer
Delfield
Certifications
NSF
Height
10.75in
Width
30.75in
Depth
26.0in
Shipping Weight
100.0lbs
Depth (front-to-back) OA
25 - 30 inches
Pan Qty
2-pan
Layout
straight
Interior Liner
stainless steel
Exterior Liner
galvanized steel
Width (side - side) OA
25 - 30 inches
Specifications
Drop-In Ice Cooled Cold Pan, 30-3/4" W x 26" D, (2) 12" x 20" pan size, fit top gasket, removable perforated false bottom, insulated, 1" drain, stainless steel top & interior, galvanized exterior, (29-3/4" x 25" cutout required), NSF
