Delfield

Delfield GAHPT2-SH Heated Cabinets & Holding Shelves

SKU: GAHPT2-SH
$20,095.99
/each
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Delfield New Arrivals

Specification Line® Pass-Thru Heated Cabinet – 2 Section, 50 cu ft

Delfield Model GAHPT2-S | easyTouch® 4.3" Touchscreen Control

Deliver perfectly held food to both sides of the line. The ENERGY STAR® qualified GAHPT2-S keeps up to 50 cubic feet of product safely between 120 °F and 200 °F, while the easyTouch® control gives you 24/7 remote visibility from any web-enabled device.

Why this heated cabinet belongs in your kitchen

  • easyTouch® 4.3" full-color touchscreen with passcode security & remote monitoring
  • (8) locking half-height solid doors – auto-close to 90° and stay open past 90° for easy loading
  • (6) adjustable chrome wire shelves fit full-size sheet pans (3 per section)
  • Ducted heater system delivers even airflow & temperature consistency
  • High/low temperature visual alarms on the exterior display
  • Incandescent interior lighting for clear product visibility
  • Stainless steel exterior front, sides & interior with tool-less removable gaskets
  • (4) 5" locking swivel casters & 10 ft cord with NEMA 6-20P plug included
  • NSF & cULus listed and ENERGY STAR® certified for efficiency
  • Backed by a 3-year parts & labor warranty plus a lifetime door-handle warranty

Smart connectivity

  • Receive temperature or door-ajar alerts instantly on your phone or tablet
  • View HACCP data logs, adjust set-points and change modes from anywhere
  • Service technicians can diagnose performance remotely, reducing downtime

Ideal for

  • High-volume QSR hold stations
  • Hotel banquets & plated meal staging
  • Pass-thru installation between kitchen & serving areas
  • Commissary or institutional foodservice

Technical specifications

Capacity 50.0 cu ft (1,416 L)
Door configuration (8) half-height solid doors, locking
Shelves supplied (6) adjustable chrome wire
Temperature range 120 °F – 200 °F (49 °C – 93 °C)
Controller easyTouch® 4.3" touchscreen with data logging & remote access
Construction Stainless steel interior & exterior, foamed-in-place insulation
Mobility (4) 5" locking swivel casters (ship loose)
Electrical 208-240 V / 60 Hz / 1-ph, 10.5 A, NEMA 6-20P
Certifications NSF, cULus, ENERGY STAR®
Warranty 3-year parts & labor; lifetime door handle

Need extra shelves, tray slides or flanged feet? Ask our team about factory-installed accessories.

Important: Casters ship loose for field installation. Maintain clearance per local code when placing the cabinet near heat sources.

Overall Dimensions:

55.22"W x 32.44"D x 79.38"H

Product Weight:

630.0 lb
Manufacturer Delfield
Brand name Specification Line
Certifications ["NSF", "cULus", "ENERGY STAR"]
Height 79.38in
Width 55.22in
Depth 32.44in
Shipping Weight 630.0lbs
Interior Finish stainless steel interior
Energy Efficiency ENERGY STAR®
Doors half-size hinged solid
Depth (front - back) standard
Size 2 section
Exterior Finish stainless steel front & sides
Interior configuration shelves
Thermometer exterior digital
Specifications Specification Line® Heated Cabinet, Pass-Thru, two-section, 50.0 cubic feet capacity, (8) half-height hinged solid doors (locking), (6) adjustable chrome wire shelves, 4.3" easyTouch® screen temperature display/control with remote monitoring, incandescent interior lighting, stainless steel exterior front, sides & interior, (4) 5" locking casters, 208-240v/60/1-ph, 10.5 amps, NEMA 6-20P, NSF, cULus, ENERGY STAR®
