Specification Line® Heated Pass-Thru Cabinet – 2-Section (GAHPT2-S)

50 cu ft | four locking solid doors | easyTouch® 4.3” control

Give plated meals, sheet pans or bulk ingredients the gentle heat they need with Delfield’s flagship pass-thru holding cabinet. Engineered for busy commercial kitchens, this two-section model delivers rock-solid temperature consistency, 24/7 remote connectivity and the rugged durability you expect from Specification Line.

Why you’ll love it

  • Wide temperature range: air-warmed 120 °F – 200 °F (49 °C – 93 °C) to suit proofing, holding or service.
  • easyTouch® interface: 4.3" full-color touchscreen with passcode protection, data logging and remote monitoring/alerts via Wi-Fi or Ethernet.
  • True pass-thru workflow: four full-height doors (front + rear) speed up tray transfer between prep and service lines.
  • Stainless-steel inside & out: seamless front, sides and interior withstand heavy daily cleaning.
  • “Smart” self-closing hinges: doors self-close under 90° and stay open past 90°—no more slamming or propping.
  • Tool-less maintenance: removable side louver and snap-in gaskets make cleaning fast.
  • Lifetime door handles: Delfield’s patented integral handles stand up to constant use.
  • Bright interior lighting: 40 W incandescent lamp illuminates every shelf.

Room for every pan

Six chrome-plated wire shelves (three per section) adjust on stainless-steel pilasters to accommodate full-size sheet pans loaded length-wise or width-wise. High-density foamed-in-place polyurethane insulation locks in heat while remaining Kyoto-Protocol compliant (Non-ODP / Non-GWP).

Technical specifications

Model GAHPT2-S
Capacity 50.0 cu ft (25.5 sq ft shelf area)
Sections / Doors 2 sections / 4 full-height solid doors (locking, field-rehingeable)
Shelves (included) 6 adjustable chrome wire shelves
Temperature range 120 °F – 200 °F (49 °C – 93 °C)
Control easyTouch® 4.3" touchscreen with remote monitoring & alarms
Electrical 208-240 V / 60 Hz / 1-ph, 10.5 A, 10 ft cord, NEMA 6-20P
Mobility (4) 5" locking casters (ships loose for field install)
Construction Stainless steel exterior front, sides & interior; removable side louver
Certifications NSF, cULus
Warranty 3-year parts & labor; lifetime door handle

Popular options & accessories

  • 6" stainless-steel feet or 6" locking casters
  • Additional chrome or stainless-steel shelves
  • Tray / pan slides (various styles)
  • Utility base or kick plate
  • Heat-shield end panels (up to 400 °F)
  • Foot-pedal door opener
Important: This unit ships with a NEMA 6-20P plug and requires a dedicated 208-240 V, single-phase circuit. Verify site power before ordering.

Upgrade your hot holding program with smart connectivity, industry-leading durability and the flexible workflow of a true pass-thru design—only from Delfield.

Overall Dimensions:

55.22"W x 32.44"D x 79.38"H

Product Weight:

630.0 lb
Manufacturer Delfield
Brand name Specification Line
Certifications ["NSF", "cULus"]
Height 79.38in
Width 55.22in
Depth 32.44in
Shipping Weight 630.0lbs
Interior Finish stainless steel interior
Exterior Finish stainless steel front & sides
Depth (front - back) standard
Size 2 section
Interior configuration shelves
Doors hinged solid
Thermometer exterior digital
Specifications Specification Line® Heated Cabinet, Pass-Thru, two-section, 50.0 cubic feet capacity, (4) full-height hinged solid doors (locking), (6) adjustable chrome wire shelves, 4.3" easyTouch® screen temperature display/control with remote monitoring, incandescent interior lighting, stainless steel exterior front, sides & interior, (4) 5" locking casters, 208-240v/60/1-ph, 10.5 amps, NEMA 6-20P, NSF, cULus
