Delfield

Delfield GAHPT1-SH Heated Cabinets & Holding Shelves

SKU: GAHPT1-SH
$11,709.99
/each
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Delfield New Arrivals

Specification Line® Pass-Thru Heated Cabinet – 1 Section, 23 cu. ft.

Model GAHPT1-SH • by Delfield

Keep plated meals, sheet pans or hotel pans hot and ready on both sides of the line. Delfield’s ENERGY STAR® qualified GAHPT1-SH combines precision temperature control, rugged stainless-steel construction and 24/7 remote connectivity in a compact, pass-thru footprint that rolls wherever you need it.

Key Features

  • 4.3" easyTouch® full-color touchscreen with passcode protection, data logging and remote monitoring
  • Heats between 120 °F – 200 °F with full-length vertical duct and out-of-compartment fan for even airflow
  • Four locking, half-height solid doors (two per side) with smart hinges that self-close under 90° & stay open over 90°
  • Three adjustable chrome wire shelves (11.5 ft² total) accept full-size sheet pans
  • Bright 40 W incandescent interior lighting
  • Durable stainless-steel interior, exterior front & sides plus patented lifetime door handles
  • Tool-less removable magnetic gaskets for quick sanitation
  • Ships with four 5" locking casters (field installed) for effortless mobility
  • High/low temperature visual alarms, door locks and pass-through convenience improve food safety
  • 10' factory-installed cord with NEMA 6-20P plug – no hard-wiring required
  • NSF, cULus & ENERGY STAR® certified; backed by a 3-year parts & labor warranty

Stay Connected

  • Monitor cabinet temps and alarms from any web-enabled device 24/7
  • Receive real-time text or email alerts for out-of-range conditions
  • Service technicians can access historic data remotely, minimizing downtime

Specifications

Capacity 23 cu. ft. (1 section)
Doors 4 half-height, pass-thru, locking
Shelves (adjustable) 3 chrome wire
Temperature Range 120 °F – 200 °F
Electrical 208-240 V / 60 Hz / 1-phase, 6.0 A
Plug NEMA 6-20P (10 ft. cord)
Casters 4 × 5" locking (included, field install)
Interior/Exterior Finish Stainless steel
Lighting 40 W incandescent
Shipping Weight Approx. 330 lb
Certifications NSF, cULus, ENERGY STAR®
Warranty 3-year parts & labor

Popular Options & Accessories

  • 6" stainless-steel legs or flanged feet
  • All-locking 6" casters
  • Additional chrome or stainless shelves
  • Tray / pan slides
  • Utility base or kick plate
  • Heat-shield end panel (up to 400 °F)
  • Foot-pedal door opener
Electrical Notice: This unit requires a dedicated 208-240 V / 20 A circuit and NEMA 6-20R receptacle. Always connect equipment in accordance with local codes.

Delfield continually improves products; specifications subject to change without notice.

Overall Dimensions:

27.4"W x 32.44"D x 79.38"H

Product Weight:

330.0 lb
Manufacturer Delfield
Brand name Specification Line
Certifications ["NSF", "cULus", "ENERGY STAR"]
Height 79.38in
Width 27.4in
Depth 32.44in
Shipping Weight 330.0lbs
Interior Finish stainless steel interior
Size 1 section
Doors half-size hinged solid
Energy Efficiency ENERGY STAR®
Depth (front - back) standard
Exterior Finish stainless steel front & sides
Interior configuration shelves
Thermometer exterior digital
Specifications Specification Line® Heated Cabinet, Pass-Thru, one-section, 23.0 cubic feet capacity, (4) half-height hinged solid doors (locking), (3) adjustable chrome wire shelves, 4.3" easyTouch® screen temperature display/control with remote monitoring, incandescent interior lighting, stainless steel exterior front, sides & interior, (4) 5" locking casters, 208-240v/60/1-ph, 6.0 amps, NEMA 6-20P, NSF, cULus, ENERGY STAR®

Certifications & Compliance

Certified badge of Energy Star Certified
Energy Star Certified
Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download PDF Flyer PDF Download PDF Video PDF Download PDF Warranty sheet PDF Download
