LiquiTec® 8118-EFP Drop-In Refrigerated Cold Pan
1-Pan • Flush-Mount • Self-Contained Eutectic SystemKeep your signature sides, salad toppings or grab-and-go entrées ice-cold and easy to reach. Delfield’s LiquiTec® 8118-EFP uses eutectic fluid technology to surround the well with 100 % cooling contact, delivering NSF-7 food-safe temperatures while sitting perfectly flush with your countertop.
Why you’ll love it
- Eutectic Fluid Cooling – 100 % liner contact for faster pull-down and steadier temps than traditional wrap systems.
- Flush-Mount Ergonomics – 12" × 20" pans (4" or 6" deep) sit level with the counter for sleek presentation and easy scooping.
- GreenGenius™ R290 Refrigeration – Ultra-efficient, zero ODP/GWP hydrocarbon system with only 1/5 HP compressor.
- Ready to Drop-In – Pre-installed press-fit gasket, 8' cord & NEMA 5-15P plug simplify installation.
- Built for the Long Haul – All-stainless well & top, galvanized outer liner and high-density foamed-in insulation.
- Smart Control – Factory-set electronic temperature controller and expansion valve maintain 33 °F–41 °F in 86 °F ambient.
At-a-Glance Specs
| Pan capacity | One 12" × 20" pan (4" or 6" deep, pans not included) |
|---|---|
| Counter cut-out | 17" W × 25" D (432 mm × 635 mm) |
| Overall well depth | 6.25" (159 mm) to drain |
| Refrigeration | Self-contained, R290, 1/5 HP compressor, 218 BTU load |
| Electrical | 115 V / 60 Hz / 1-Ph, 2.4 A, NEMA 5-15P cord & plug |
| Drain | ½" stainless drain with copper manifold |
| Certifications | cULus, NSF 7, R290 marking |
| Shipping weight | Approx. 180 lb (82 kg) |
| Warranty | 1 year parts & labor (standard) |
What’s included
- Stainless steel louver for field installation
- Non-marring press-fit top gasket
- Installation & operation manual
Popular factory options (sold separately)
- Flip-up single or double-service sneeze guards
- Drain valve kit
- Remote refrigeration or compressor relocation
- 220 V / 50 Hz export electrical
Need a larger line-up? 2- to 6-pan LiquiTec® models are also available.
Contact us for lead-times, drawings or customization assistance.
Heads up: Food pans and adapter bars are not included and are shown for illustration only.
$6,062.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Delfield 8118-EFP LiquiTec drop-in refrigerated food well: stainless interior, insulated pan, R290 eco refrigerant, 1/5 hp, NSF/cUL listed.
Manufacturer
Delfield
Brand name
LiquiTec
Certifications
NSF, UL
Height
24.24in
Width
18.2in
Depth
26.0in
Shipping Weight
180.0lbs
Finish
stainless steel top & inner liner, galvanized outer liner
Width (side - side)
13 - 18 inches
Pan Qty
1-pan
Style
self-contained refrigeration
Layout
deep
Insulation
insulated
Pan Size
full-size (12" x 20")
Specifications
LiquiTec® Drop-In Cool Food Unit, 1-pan size, 4" or 6" deep pans flush with counter top, insulated pan, stainless steel inner liner & top, galvanized outer liner, self-contained Eutectic fluid refrigerated system, R290 Hydrocarbon refrigerant, 1/5 hp, (17" x 25" cutout required), cUL, UL, NSF
