Curtron Products

Curtron Products Curtron X-HD S-XHD-48-1 Extra Heavy-Duty Unheated Industrial Air Curtain, 48"W, 5 HP Single Motor, Up to 22' High

SKU: S-XHD-48-1
$9,061.24
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Curtron X-HD S-XHD-48-1 is an extra heavy-duty unheated industrial air curtain for openings up to 48 inches wide and doors up to 22 feet high.

  • Powered by one continuous-duty 5 hp motor.
  • Features a stainless steel housing and remote mounted control panel.
  • Made in USA.

Overall Dimensions:

51.0"W x 27.25"D x 21.0"H

Product Weight:

400.0 lb

Unheated operation

This air curtain is designed without heat.

Single 5 hp motor

Uses one continuous-duty 5 hp motor.

Opening coverage

Covers openings up to 48 inches wide and is specified for doors up to 22 feet high.

Stainless steel housing

Built with a stainless steel housing.

Remote mounted control panel

Includes a remote mounted control panel.

Made in USA

The product is identified as Made in USA.

Related Searches

Air Doors Best Sellers Curtron Products Equipment Facility & Ventilation Equipment Facility Air Curtains Kitchen Ventilation & Climate Control New Arrivals Restaurant Equipment
Product type Extra heavy-duty industrial air curtain
Heating Unheated
Opening coverage Up to 48 in wide
Maximum opening height 22 ft
Number of motors 1 motor
Motor duty Continuous duty
Horsepower per motor 5 hp
Nozzle width 48 in
Housing material Stainless steel
Control panel Remote mounted
Maximum air velocity at nozzle 6,770 fpm
Average air velocity at nozzle 5,665 fpm
Airflow at nozzle 6,495 cfm
Outlet uniformity 92%
Sound level 71 dBA measured 10 ft from the unit in a free field
Motor voltage 208/230/460/575 V, three phase
Amp draw per motor 17.1 A at 208 V; 15.8 A at 230 V; 7.9 A at 460 V; 6.3 A at 575 V

Documents

PDF Cutsheet PDF Download PDF Parts list PDF Download PDF Marketing sheet PDF Download PDF Installation manual PDF Download PDF Instructions PDF Download

Frequently Asked Questions

No. The S-XHD-48-1 is an unheated air curtain.
It covers openings up to 48 inches wide.
It is specified for doors up to 22 feet high.
It has one continuous-duty 5 hp motor.
The housing is stainless steel.
Yes. It includes a remote mounted control panel.
The product is 51.0 inches wide, 27.25 inches deep, and 21.0 inches high, with a listed weight of 400.0 pounds.
