Description

Crown SCX-2-10 Two-Compartment Convection Steamer / 10 Gal Kettle

Steam-coil boiler base • 3 × 12" × 20" pan capacity per compartment

Maximise production while minimising footprint with Crown’s SCX-2-10. This self-contained steamer-kettle combination gives you two independent 1-cu-ft chambers plus a 10 gal tilting kettle – all powered by an energy-efficient steam-coil boiler that needs only 25-45 psi incoming steam. Built for heavy-duty institutional use, the SCX series pairs 316 SS cooking chambers with a fully welded 304 SS cabinet for years of corrosion-free service.

Key advantages

  • Independent 60-min electromechanical timer, ready light & cook light for each compartment
  • Automatic steam shut-off when a door is opened; cooking cycle resumes when closed
  • Removable 304 SS pan supports & drip trough for fast clean-down
  • 10 gal kettle with steam coil jacket – perfect for soups, sauces & stocks
  • Deck-mount faucet valve with swing nozzle & integral rinse sink keeps the line moving
  • Factory-installed water treatment system, split water line & automatic blow-down safeguard boiler life
  • CSD-1 controls, high-limit pressure control & safety relief valve for code-compliant peace of mind
  • 6" stainless legs with adjustable flanged feet for secure floor mounting
  • cCSAus & NSF certified; ASME-code stamped boiler

Capacities

Steaming compartments 2 × 1 cu ft (14" W × 17" H × 21" D each)
Pan capacity (per cavity) 3 × 12" × 20" × 2½" pans | 2 × 4" pans | 1 × 6" pan
Kettle size 10 gal (38 L) hemispherical, steam-coil heated
Total production 200 lb / hr steam flow @ 9-11 psi chamber pressure

Specifications

Cabinet width 55.5" (1410 mm)
Depth (to rear of kettle) 48" (1219 mm)
Overall height 61.1" (1553 mm) on 6" legs
Construction Chambers – 316 SS, Cabinet – 304 SS, welded satin finish
Boiler type Steam-coil; 25-45 psi incoming steam (¾" IPS)
Electrical 115 VAC 1-Ph 60 Hz, 2 A per cavity (½" conduit)
Water connections Feed ½" NPT, hot & cold faucet ⅜" OD, 2" IPS drain
Shipping weight 750 lb (340 kg)

Included safety & control package

  • Automatic water level control with sight glass
  • Pressure gauge plus adjustable operating pressure control
  • High-limit pressure control & ASME safety relief valve
  • Automatic boiler blow-down cycle
Water quality matters. For full warranty coverage, supply water must be treated and maintained below 60 ppm TDS and 1.5 ppm chlorine. Crown’s factory-installed treatment cartridge makes compliance easy— remember to purge 2-3 gal of water after each cartridge change.

Need financing? Middleby Equipment Financing offers same-day credit decisions and fixed monthly payments – ask your Crown representative for details.

Features & Specs

Manufacturer

Crown (Middleby)

Certifications

NSF, cCSAus

Height

61.13in

Width

48.0in

Depth

33.0in

Shipping Weight

750.0lbs

Kettle

(1) 10 gal

Compartments

2

Pan Capacity per Compartment

(3) 12"x20"x2-1/2" deep

Width (side - side)

48"

Specifications

Convection Steamer/Kettle, steam coil, (2) compartment, (1) 10 gallon kettle, (3) 12" x 20" pan capacity per compartment, 48" cabinet base, automatic blowdown, 60 minute timer per compartment, removable pan supports & drip trough, deck mount faucet valve, swing nozzle & integral sink, automatic water level control, pressure gauge, water gauge glass, operating pressure control, high limit pressure control & safety relief valve, CSD-1 code package, water treatment system, split water line, 316 stainless steel liner, 304 stainless steel construction, 6" legs, adjustable flanged feet, cCSAus, NSF
