Crown (Middleby)  |  SKU: GCX-2-10

Crown (Middleby) GCX-2-10 Steam Kettles

$53,875.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Installation & operation manual Parts list Crown steam group letter Warranty sheet
Related Searches
Steam Cooking Equipment Steam Kettles

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Crown GCX-2-10 Gas Convection Steamer & 10-Gallon Kettle

48" cabinet base • two independent 3-pan compartments • 250,000 BTU steam boiler

Boost production, cut ticket times and consolidate space with Crown’s GCX-2-10 combination steamer/kettle. A high-output gas-fired boiler delivers an endless supply of 9-11 psi steam to two pressureless compartments while a heavy-duty 10 gal (38 L) kettle handles soups, sauces and stocks—all from one 48" footprint.

Why chefs choose the GCX-2-10
  • True menu-flexibility – steam, retherm, braise or poach while a full-size kettle works in parallel.
  • Independent 60-min mechanical timer per compartment with audible buzzer for fool-proof batch cooking.
  • Factory-installed water treatment system and split water line protect the boiler and extend warranty coverage.
  • Electronic ignition & automatic blowdown for one-touch starts and simplified daily shutdown.
  • Deck-mount faucet valve, 14" swing nozzle & integrated sink speed kettle fill/clean-up.
  • 316 SS cooking chambers + 304 SS exterior for unmatched durability in high-acid environments.
  • Meets CSA Flame, CSA Star & NSF sanitation standards; boiler is ASME code stamped & National Board registered.
Pan & kettle capacities
Steamer compartments 2 independent chambers
Per compartment capacity 3 × 12" × 20" × 2.5" pans (or 6 × 1" pans / 2 × 4" pans / 1 × 6" pan)
Kettle size 10 gal / 38 L (steam jacketed)
Built to last
  • All-welded 316 SS compartment liners—fully insulated to lock in heat, stay cool to touch.
  • One-piece 304 SS exterior with #4 satin finish looks sharp and wipes clean fast.
  • Positive-lock, gasketed doors with stainless drip trough keep floors dry.
  • 6" stainless legs with adjustable flanged feet (front) for bolting to the floor.
  • Full-perimeter, painted angle frame reinforces the base for heavy commercial use.
Controls & safety
  • CSD-1 compliant boiler controls with automatic water level, pressure gauge & high-limit protection.
  • 9-11 psi operating pressure for fast heat transfer without over-cooking delicate items.
  • Each compartment shuts steam flow when door is opened; steam resumes automatically when closed.
Utility connections
Gas 250,000 BTU/hr, 3/4" IPS connection
Natural gas 7–14" WC | LP 11–14" WC
Electrical 115 VAC, 1 ph, 50/60 Hz, 2 A per compartment
Boiler feed water 1/2" NPT, 25–50 psi (170–345 kPa)
Hot water (faucet) 3/8" OD tubing, 25–50 psi
Drain 2" IPS open floor drain
Overall footprint 48" W × 35" D × 66" H (shipping weight ≈ 1,030 lb)
Important: For optimum performance and warranty protection, incoming water must not exceed 60 ppm TDS, 2 gr/gal hardness or 1.5 ppm chlorine (pH 6.8–7.3). The included filtration system must be installed and cartridges replaced per manufacturer guidelines.
What’s in the box
  • GCX-2-10 steamer/kettle unit on 48" cabinet base
  • Factory-mounted water filter & cartridges
  • Deck faucet with swing nozzle & rinse sink
  • Removable pan racks & kettle draw-off valve
  • Installation & operation manual
  • 1-year parts & labor warranty (10-year kettle hemisphere warranty)

Need financing? Ask about Middleby Equipment Financing for fast credit decisions and affordable monthly payments.

Features & Specs

Manufacturer

Crown (Middleby)

Certifications

NSF, CSA Star, CSA Flame

Height

65.13in

Width

48.0in

Depth

33.0in

Shipping Weight

1030.0lbs

Pan Capacity per Compartment

(3) 12"x20"x2-1/2" deep

Kettle

(1) 10 gal

Width (side - side)

48"

Compartments

2

Specifications

Convection Steamer/Kettle, gas, (2) compartment, (1) 10 gallon kettle, (3) 12" x 20" pan capacity per compartment, 48" cabinet base, electronic ignition, automatic blowdown, 60 minute timer per compartment, deck mount faucet valve, swing nozzle & integral sink, CSD-1 code package, includes water filter system, split water line, 316 stainless steel interior liner, 304 stainless steel exterior, 6" legs, adjustable flanged feet, CSA Flame, CSA Star, NSF
