Crown EL-60F 60-Gallon Full-Jacket Electric Stationary Kettle
316 Stainless Interior | Tri-Leg Mount | 24 kW Standard (33 kW Optional)Engineered for high-volume, high-acid cooking, the Crown EL-60F delivers 60 gallons of even, steam-jacketed heat in a compact, low-profile tri-leg frame. With a 316 stainless steel liner, spring-assist domed cover and sanitary 2 inch draw-off valve, this powerhouse kettle helps you batch, blanch, braise or simmer with speed, precision and safety.
Key Advantages
- Full-jacket, self-generating steam system – no external boiler required.
- Hemispherical bottom maximizes heat transfer for faster, more even cooking.
- Wide 165 °F – 285 °F (74 °C – 140 °C) thermostatic range; low-water cutoff protects elements.
- 2 ″ sanitary draw-off valve with included perforated strainer speeds portioning & cleaning.
- Spring-assisted hinged stainless steel cover reduces operator fatigue.
- Built-in faucet bracket keeps kettle fillers or rinse faucets within easy reach.
- Seam-welded 304 stainless exterior with #4 satin finish stands up to daily abuse.
- ASME code stamped, National Board registered; cCSAus & NSF certified.
Operator-Focused Control Panel
- Illuminated power switch & thermostat dial
- Heating & low-water indicator lights
- Vacuum/pressure gauge (0–50 psi) with 50 psi safety relief valve
Specifications
| Model | EL-60F (Stationary) |
|---|---|
| Usable capacity | 60 US gal / 227 L |
| Interior material | 316 SS (acid-resistant) |
| Exterior material | 304 SS, #4 finish |
| Heating power | 24 kW standard | 33 kW optional |
| Electrical | 208, 220, 240, 380, 415, 480 or 600 VAC, 3-ph |
| Temperature range | 165 °F – 285 °F (74 °C – 140 °C) |
| Operating pressure | 0 – 50 psi (345 kPa) |
| Included accessories | 2 ″ draw-off valve + strainer, spring-assist cover, faucet bracket |
| Mounting | 3 × stainless tubular legs with flanged, adjustable feet (floor-secure) |
| Overall dimensions* | W 35.5″ × D 38.5″ × H 75.1″ |
| Shipping weight | 460 lb / 209 kg |
| Clearance | 3″ (sides & back) |
| Certifications | cCSAus, NSF, ASME, National Board |
| Warranty | 10-year kettle hemisphere; 1-year parts & labor |
*See spec drawing for detailed dimension references (A–L values).
Popular Factory Options (extra cost)
- 33 kW high-performance element package
- 3 ″ draw-off valve with perforated strainer
- Etched gallon or litre graduations
- Single or double pantry kettle fillers
- One-piece lift-off or two-piece hinged covers
